HOT SALE! high quality dongfeng 6cbm Intelligent type asphalt spreading tanker vehicle, 5T bitumen distributing truck for sale
The bitumen distribution truck for sale are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48 nos.
The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
Our asphalt distributor dopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.
Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.
Advantages of chengli sensor emulsified asphalt distributor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1.The temperature rising speed is 5% faster than the trucks manufacture by other factory.
2.With conducting oil system, asphalt both in the tank and in the nozzle are all hot, easy to spray, no remained.
3.High quality metal hose, won't broken, long service life.
4.The distribution width can be adjusted according to your demand from 4.5m to 6m.
5.Start quickly, though the truck stop, still can distribute.
If you're interested in our asphalt tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of intelligent type dongfeng 6cbm 5tons asphalt distributing tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
The devices of intelligent type dongfeng brand 6cbm 5tons asphalt distributing vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
1, the asphalt pump adopts high quality QGB680 (high viscosity asphalt pump, 680L/min).
2, hydraulic system: Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve, radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L;
3, control way: Intelligent touch screen computer control at the driver cab; control system: (Siemens, Germany), 34 sets intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil
5, gasoline generator unit: 6KW
6, spreading amount: 0.25-3L/㎡;
7, asphalt distributing width: 4.5m, 39 sets spraying nozzles for 6m spreading width is selective (8000RMB additional).
8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
Main technical parameter of Dongfeng asphalt spreading tanker truck manufactured by Chengli Special Automobile CO., Ltd. as below.
| Main technical parameters |
| Product name |
CLW5100GLQ3 6cbm asphalt spreading vehicle for sale
|
| Total mass(Kg) |
9750 |
Tanker volume (m3) |
6 |
| Rated mass(Kg) |
3955 |
Overall dimension(L*W*H)(mm) |
7080×2300×2650 |
| Curb mass(Kg) |
5600 |
Driver cab seated person |
3 |
| Approach/departure angle(°) |
22/10 |
Front/rear suspension(mm) |
1180/2100 |
| Axle nos. |
2 |
wheelbase(mm) |
3800 |
| Axle load(Kg) |
3400/6350 |
Max speed(Km/h) |
80 |
| Chassis main parameters |
| Truck chassis model |
EQ1110T9ADJ3AC |
Manufacturer |
Dongfeng |
| Approach/departure angle(°) |
22/13 |
Tire specification |
7.50R16*6 |
| Steel spring |
11/9+7 |
tread(mm) |
1831 |
| Fuel type |
Diesel |
Rear tread(mm) |
1640 |
| Emission standard |
Euro Ⅲ |
| Engine model |
Manufacturer |
displacement(ml) |
power(Kw) |
|
CY4102-E3C
YC4FA120-33
|
Chaocahi
YUchai
|
3856
2982
|
88
88
|
