Place of Origin: | China |
Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20days |
Payment Terms: | L/C, T/T |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Axles: | HIgh Quality 3* FUWA/BPW Axles |
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of garbage trucks in China. With many years' development, Chengli Special Automobile Co., Ltd. could offer garbage compactor truck, dump garbage truck, swing arm garbage truck, sealed garbage truck, hook lift garbage truck, etc. More information, please feel free to contact with Ms. Anita.
Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
main technical advantages of CLW brand dump tipper trailer manufactured by Chengli Special Automobile Co., Ltd. as below.
1, Made by high tensile strengh steel, Q345B, Q610, 700
2, heave duty loading capacity. Dumper volume: 25M3-55M3.
3, square shape or U-shape design, nice appearance.
4, Hydraulic system: A set of HYVA Brand cylinder.
5, 40HQ container loading, save a lot reight.
6, Factory directly selling, high quality and compective price.
If you're interested in our dump tipper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of hot sale CLW brand 3 axles dump tipper semitrailer as below.
HOT SALE! CLW brand 3 axles dump tipper trailer
Factory sale best price CLW brand 36tons tipper semitrailer for sale
Main technical parameters of hot sale CLW brand 3 axles dump tipper semitrailer manufactured by Chengli Special Automobile Co., Ltd. as below.
Trailer Model | Dump Trailer |
Model Number | CLW9400 |
Dimension(Lx W x H) | 11300x2500x3600mm |
Inner Dimension | 10500x2300x1500mm |
Volume | 36 m3 |
Wheelbase(mm) | 5100+1320+1320mm |
Track | 1840/1840/1840mm |
Axle | FUWA brand 13 TON Axle |
Axle Number | Three |
Lifting | Front hydraulic lifting system ,China famous brand |
Suspension system | Mechanical suspension, Three axis series balanced steel plate spring suspension |
Steel Spring | 10/10/10 leaf spring suspension |
Curb Weight(kg) | 12000kg |
Max Total Weight(kg) | 50000kg |
Main beam |
I shape, 500mm Height, Mild Alloy(Q345B, tensile strength 34.5kg/mm^2) by Automatic submerged arc welding. upper plate is 16mm, middle plate is 12mm, down plate is 18 mm, side 6 mm, bottom 8mm |
Traction Pin | Φ90MM |
TireType and quantity | 12.00R20 12units, double star brand |
Front Fitting Radius (mm) | 1760 |
Landing Gear | FUWA brand, 28ton,two speed manual operation |
Brake system | Standard system, None ABS system |
Brake air chamber | Two double and two single chamber |
Electrical system | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
Tail lamp with turn signal, brake light & reflector, side lamp etc. | |
One set 6-core standard Cable. | |
Painting |
Sand blasting before painting; 2 coat of anticorrosive primer ; Color as per request |
Packing | Nude, Polish with wax before shipping |
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat/Mob.: +86 13329899995
Skype: truck0011
QQ: 504873236
