|Place of Origin:||China|
|Certification:||CCC, ISO 9001|
|Minimum Order Quantity:||1 unit|
|Packaging Details:||in bulk package, waxed|
|Color:||Different Color Upon Request||Price:||High Quality Factory Direct Sale Price|
|Volume:||18m3-22m3 Tank Volume With 3 Compartments For 3 Different Feed Pellet||Discharging Way:||Electronic System Discharging Or Hydraulic System Discharging|
HOT SALE! good price FAW 4*2 LHD 10tons bulk feed fodder transporting truck , electronic discharging bulk feed truck
FAW 4*2 bulk feed trucks, Loading configuration: effective volume of 20 cubic, can hold 12 tons of bulk feed, standard 3 positions, electric dragon unloading, dumping tube tilt 60 degrees, the vertical discharge height of 7 meters, when the vehicle unloading finished with 20 minutes.
Chassis configuration: Liberation J6 feed truck chassis, Diesel 180 horsepower engine, the country five emissions, 6 gearbox, 280 double girder, front axle 4.5 tons, rear axle 9 tons (reinforced front and rear leaf springs), 10.00R20 steel tire , Out of gas brake, exhaust brake.
And the clients can choose electronic auger type( with three phrase power) or hydraulic auger type(without 3 phrase electronic power) discharging way.
The bulk feed tank volume is 20cbm(can be loaded 10on feeds according to the density of the bulk feeds), adopting electronic auger type transferring feeds, putting on 380 Volt three mutually alternate current, then working. Discharging is by electronic motor driven the screw mechanism with high speed, continuous working, highly improving the working productiveness.
The feed tank is usually with 3 compartments, loading and discharging with three different kinds feeds. Simple unit-structures and electric cabinet unity is at the rear part of the tank. The bulk feed truck is easy and flexible to operate and maintenance.
If you're interested in our bulk feed truck, please send email to firstname.lastname@example.org or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of FAW 10tons bulk feed fodder pellet truck manufactured by Chengli Special Automobile Co., Ltd. as below.
high quality and competitive price FAW brand bulk feed delivery truck for sale
Factory sale best price FAW brand 10tons farm-oriented livestock poultry feed truck
main technical parameters of FAW brand bulk feed delivery truck manufactured by Chengli Special Automobile Co., Ltd. as below
|FAW J6 feed delivery truck main parameters|
|Product name||Bulk feed truck for sale||Product brand||CLW brand|
|Truck model||CLW5160ZSLC4 feed pellet truck||Loading capacity||6tons-12tons|
|Overall dimension(L*W*H)||9000(mm)*2470(mm)*3650(mm)||Tank volume||12~22m3|
|Total mass||16000(kg)||Power steering||Yes|
|Curb mass||8885(kg)||Rated mass||6920(kg)|
|Axle nos.||2||Max speed(km/h):||90|
|Gearbox||8||Rear axle||11tons rear axle|
|Tyre nos.||6||Tyre specification||10.00R20 18PR|
|Feeding height||8.2m||Feeding distance||7.2m|
|Discharging speed||≥510(kg/min)||residual rate||≤0.10%|
|Lead time||10 working days||Price|
|Chassis emission standard||Euro Ⅳ|
|Feed tank main parameters|
|Tank material||High quality carbon steel||Tank cimension(L*W*H)||6050*2400*1850|
|Tank volume||12~22m3||Loading capacity||Real loading capacity: 6tons-12tons(Density: 500kgs/cbm)|
|Transporting medium||puffing/pellet feed, powder, corn, etc.||Discharging speed||≥510(kg/min)|
|Full discharging time||25minutes||Discharging max elevation angles||70°|
|Horizontal feeding distance||7.2m||Discharging roration angle||360° (single part 180°)|
|Vertical feeding distance||8.2m||Compartments||Standard with 3 compartments for feeding and discharging 3 different kinds feed|
More pictures of FAW brand 8tons-12tons farm-oriented and livestock poultry feed truck manufactured by Chengli Special Automobile Co., Ltd. as below.
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat: +86 13329899995
