Factory sale good price Shangqi Yuejin 4*2 LHD gasoline smallest street sweeping vehicle, road sweeper truck
CLW brand road sweeping truck is installed with middle 4pcs cleaning brushes, and rear part with suction mouth, so the truck cleaning effect is good and the truck water tanker and garbage box made by SS340 stainless steel.
Garbage box and the water tank is an integral structure, water tank in the dustbin garbage box bottom plate bottom pretilt angle up to 12°, easy to dump clean.
Garbage box is arranged on the top of the guide groove and a larger area of the filtering net, can fully improve the efficiency of dust removal, so that garbage piles evenly, increase effective capacity, reduced due to a blocked filter and the air resistance.
If you're interested in our refrigerated truck, please send email to firstname.lastname@example.org or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
SHANGQI yuejin brand 4*2 LHD gasoline smallest road sweeping truck, adopts Yuejin 4*2 LHD single row driver cab,2650mm wheelbase, China-made liuji LJ469Q-AE8 Euro 5 gasoline 87hp engine, 5 speed gearbox, , 185R14 6PR *6, etc.
There are 4 sets middle-installed sweeping plates, SANYO motor, LN 31hp auxiliary engine or yangzhou power 40hp auxiliary engine, Schneider controlling switches, HI-PRESSURE solenoid valves, Continuously variable automatic clutch, maintenance-free centrifugal fan, stainless steel dust tank, Polaris brand Electronic pump, dust tank lifting and tipping, rear part with arrow LED lamp, Manual pump emergency system ,etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of road sweeper trucks in China. With many years’ development, we Chengli Special Automobile Co., Ltd. could offer ISUZU road sweeper truck, forland street sweeper truck, dongfeng brand road cleaning vehicle, JMC brand road sweeping vehicle, JAC brand street sweeper, FAW brand street sweeping vehicle, etc. More information, please feel free to contact with Ms. Anita.
More pictures of Yuejin 4*2 LHD gasoline street sweeper vehicle manufactured by Chengli Special Automobile Co, Ltd. as below.
High quality and competitive price Yuejin Brand gasoline road sweeper truck for sale
Customized CLW brand gasoline street sweeper truck for sale
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat: +86 13329899995
main technical parameters of cheapest new design yuejin mini gasoline road sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below
|Main technical parameters|
|Product name||Yuejin xiaofuxing mini gasoline road sweeping truck for slae|
|Total mass(Kg)||3495||Overall dimension(L*W*H)(mm)||5200×1600×2100|
|Rated mass(Kg)||405||Curb mass(Kg)||2960|
|Driver cab seated person||2||Front/rear suspension(mm)||1080/1470|
|Alxe nos.||2||Max speed(Km/h)||95|
|Axle load(Kg)||1290/2205||Emission standard||Euro Ⅴ|
|Chassis main parameters|
|Truck chassis||SH1032PBGBNZ2||Tires nos.||6|
|Approach/departure angle(°)||17/14||Tire specification||185R14 6PR|
|Steel spring||3/5||Front tread(mm)||1316|
|Fuel type||gasoline||Rear tread(mm)||1223|
|Sweeping devices||1, the volume of the stainless steel is 0.8cbm; while the volume of the stainless steel dust hopper is 1.7cbm.
2, middle-installed sucking disk,
3, Schneider control switch
4, LN 31hp auxiliary engine or Yangzhou power 40hp auxiliary engine
5, stainless steel dust hopper
6, HI-PRESSURE electromagnetic valve unit.
7, infinite variable speed automatic clutch,
8, maintenance-free centrifugal fan,
9, high precision filter system for the dust hopper(max up to 0.3micronmeter),
10, imported sentinel valve,
11, tail with LED arrow lamp,
12, manual pump emergency system
13, tail with mist spraying and wetting system
