|Place of Origin:||China|
|Certification:||CCC, ISO 9001|
|Minimum Order Quantity:||1 unit|
|Packaging Details:||in bulk package, waxed|
|Payment Terms:||T/T, L/C|
|Color:||Different Color Upon Request||Price:||High Quality Factory Direct Sale Price|
|Material:||High Quality Q345R Material For Lpg Gas Pressure Vessels||Axles:||HIgh Quality BPW/FUWA Axles For Lpg Gas Pressure Vessels|
Factory sale best price CLW brand 40m3 bulk propane gas tank semitrailer, HOT SALE! 40,000Liters road transported lpg gas storage tank
We can also manufacture ASME standard lpg gas trailer, lpg gas tank, lpg gas truck, skid lpg gas filling plant, etc. And we can design and produce lpg gas pressure vessels customized.
Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl ether, methanol, butadiene, butane, ethylene oxide, methylamine, etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 120 cubic optional. Besides, the lpg gas tank, Chengli Special Automobile Co., Ltd. could offer lpg gas trailer, lpg gas delivery truck, lpg gas dispenser vehicle, skid lpg gas filling plant, etc. More information, please feel free to contact with Ms. Anita Deng.
main technical parameters of CLW brand 40m3 propane gas tank semitrailer manufactured by Chengli Special Automobile Co., Ltd. as below
|Loading medium||LPG gas||Medium characteristic||flammable and combustible||Safety valve||1*DN100|
|Curb mass (kg)||13415||Tanker||Designed pressure(Mpa)||1.61MPa||
GB/T19905-2005 <<Liquefied Gas Tank Car>>
|Loading mass(kg)||17010||Filling ratio(kg/cbm)||420|
|Max total mass (kg)||30425||Tanker material||Q345R|
|Wheelbase(mm)||6720+1320||Tanker designed thickness(mm)||10.62|
|Front/rear suspension(mm)||-/1500||Head designed thickness(mm)||10.59|
|Overall dimension(L*W*H)(mm)||11324*2500*3730||Tanker body dimension(L*W*H)(mm)||2200*12*11054||Chengli Special Automobile Co., Ltd.|
40cbm LPG tanker semitrailer for LPG GAS adopts 13ton FUWA double axles, 12 sets 12.00-20 vacuum tyre, and another spare tyre, JOST 28ton outrigger, JOST traction pin, fire extinguisher bottle, anti-static tape.
The standard devices are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton FUWA bridges, 12 sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, with ABS, etc.
The LPG tanker semi-trailer is line with the GB150-1998
More pictures of CLW brand 40m3 bulk lpg gas tank semitrailer manufactured by Chengli Special Automobile Co., Ltd. as below.
high quality and competitive price CLW Brand lpg gas tank trailer for sale
HOT SALE! high quality and compeititve price 40M3 lpg gas tank semitrailer
customized CLW brand 40,000Liters bulk lpg gas tank trailer for sale
More informaiton, please contact with Ms. Anita.
