Customized truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
main technical advantages of CLW brand mobile truck with crane manufactured by Chengli Special Automobile Co., Ltd. as below
1. Truck crane is specially designed and produced on the basis of common cargo trucks or dump trucks, but need strong chassis frame with high strength to support the crane when lifting heavy cargos.
2. Our product type is available in 1 tons~200 tons capacity crane, correspondingly the truck chassis wheel drive from 4x2/4x4/6x2/6x4/6x6/8x4/x10x4.
3. Special crane design:common the end of crane is a hook linked with stee rope, but we can mount a gripping device, holder or other special designed mechanism to achieve the functions of gripping action to hold cargos, not always hooking cargo.
4. Hydraulic system: all the actions of crane and outriggers are driving by hydraulic system, high quality sealed oil cylinder and hydraulic pipe,etc.
5. Control system: for lifting capacity under 6 tons, crane is controlled by the operation handles on both sides; over 8 tons, on the top of crane, there is a seat and operation handles on the top of crane.
6. Cargo box: box length from 3meters to 10 meters and can produce according to your special requirements, you can check from the following photos below.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anitaby Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of SINO TRUK HOWO 4*2 LHD 6.3tons telescopic boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
the specification of SINO TRUK HOWO 6.3TONS truck with crane as below.
| Product name |
SINO TRUK HOWO 4*2 LHD 6.3tons telescopic boom mounted on truck for sale |
| Chassis type |
ZZ1167G451CE1 |
| Parameters |
Overall dimension length/width/height (mm) |
8215×2500×3650,3750,3850 |
| Cargo body dimension (L*W*H)(mm) |
5420×2300,2400×550,600 |
| GVW(kg) |
15795 (Kg) |
| Kerb Mass(kg) |
8450 (Kg) |
| Rated mass(kg) |
7215,7150 (Kg) |
| Approach angle/ Departure angle(mm) |
19/17 (°) |
| Front suspension/rear suspension(mm) |
1160/2555, |
| Fuel Type |
diesel |
| Max Speed |
95 |
| Engine |
Type |
ISF3.8s5168 |
| Displacement/Power(kw) |
3760ml/125KW/168hp |
| Manufacturer |
FOTON Cummins Engine Co.,Ltd |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
4500 |
| Tread(front/rear) |
1805/1800 (mm) |
| Transmission |
SINO TRUK 10 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
SINO TURK HOWO Light duty 2080mm one row and a half driver cab |
| Number of spring axle(front/rear) |
9/12+9 |
| Tire Type |
9.00R20 rail tires* 6+1 |
| Front axle/rear axle |
2.7T/7.2T |
| Air-condition |
Choose to install |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
5420×2300,2400×550,600 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 6.3T 3/4 sections telescopic crane boom |
| Crane boom lifting height |
10.6m/13m |
| Crane boom working radius |
13m/11m |
| Rotation |
Full hydraulic, full rotation |
| The color of the whole truck is upon request. |
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.
Whatsapp/Wechat/Mob.: +86 13329899995
Email: truck0011@163.com; anitadeng1027@hotmail.com
