CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.
Product Notes of CLW brand truck mounted crane manufactured by Chengli Special Automobile Co., Ltd. as below.
· Optional: from 2 ton to 200 ton lifting capacity crane truck
· Optional: straight arm and floding arm truck crane with or without remote control
· Optional: different famous crane brand: HIAB, Shimei, Zoomlion, Sany, Chengli balong, etc.
· Optional: different famous chassis brand: Dongfeng, FAW, Foton, Sinotruk, Syter, Shaanxi, T-king, Dayun, Yuejin, JMC, JAC, etc.
· Factory direct sale, low price and good quality.
If you're interested in our truck with crane, please kindly send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Customized liuqi brand 8*4 LHD 14TONS telescopic crane boom mounted on truck for sale, cargo truck with telescopic crane truck for sale
Customized liuqi brand 8*4 LHD truck with crane, adopts liuqi brand H5 one row and a half driver cab, 2100+4350+1350mm wheelbase, 10 speed gearbox, 2*5.5T front axles, 11.00R20 rail tires, air conditioner, etc.
The cargo body dimension of Liuqi Brand 8*4 LHD truck with crane is 7800×2470,2450×550(mm);client choose to install China made CLW brand high quality 12tons-16tons telescopic crane boom, etc.
hot sale! LIUQI brand 14tons telescopic crane boom mounted on truck
High quality and competitive price Qiuqi Brand 14tons telescopic truck with crane for sale
The specification of LIUQI brand 8*4 LHD 350hp diesel 14T telescopic crane boom mounted on truck as below.
| Product name |
LIUQI brand 8*4 LHD 350hp diesel 16tons knuckle crane boom mounted on truck |
| Chassis type |
SX1181GP5 LZ1310M5FBT |
| Parameters |
Overall dimension length/width/height (mm) |
12000×2550×3780,3960 |
| Cargo body dimension (L*W*H)(mm) |
7800×2470,2450×550 |
| GVW(kg) |
31000(Kg) |
| Kerb Mass(kg) |
16160 (Kg) |
| Rated mass(kg) |
14710 (Kg) |
| Approach angle/ Departure angle(mm) |
19/11 (°) |
| Front suspension/rear suspension(mm) |
1512/2738 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
YC6L350-50 |
| Displacement/Power(kw) |
8424ml/257KW/350hp |
| Manufacturer |
YUCHAI |
| Chassis |
Drive Type |
8*4 |
| Wheelbase(mm) |
2100+4350+1350, |
| Tread(front/rear) |
2080/2080; 1874/1874 (mm) |
| Transmission |
10 speed manual gearbox |
| Braking system |
Air braking |
| Cab |
LIUQI H7 one row and a half luxurious driver cab |
| Number of spring axle(front/rear) |
3/3/4 |
| Tire Type |
11.00R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
7800×2470,2450×550(mm) |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install XCMG 14T 4sections telescopic crane boom |
| Lifting height |
19.1m |
| Working radius |
17.1m |
| The color of the whole truck is upon request. |
