HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale

HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale

    • HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale
    • HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale
    • HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale
  • HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale

    Product Details:

    Place of Origin: China
    Brand Name: dongfeng
    Certification: CCC, ISO 9001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package, waxed
    Delivery Time: 20 days
    Payment Terms: T/T, L/C, T/T
    Supply Ability: 20units/month
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request Price: High Quality Factory Direct Sale Price
    Truck Chassis: China Made High Quality Diesel Truck Chassis Material: High Quality Dongfeng Brand 4*2 LHD Diesel Truck Chassis



    HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale



    Truck crane ,also called boom truck crane,mobile truck crane , truck mounted crane , hydraulic folding truck crane,telescopic straight boom crane,truck with crane , crane lorry,hydraulic arm crane for trucks,pickup truck mounted crane,light truck with crane,folding arm hydraulic lift platform,hydraulic crane telescopic boom,mobile crane price ,self loader truck with boom crane,new forland lorry truck mounted crane,telescopic boom truck mounted crane,flatbed knuckle boom truck crane,6 wheelers truck with crane boom truck cranes sale etc.

    A crane mounted on a truck carrier provides mobility for this type of crane. This crane has two parts: the carrier, offer referred to as the lower, and the lifting component which includes the boom, referred to as the upper. These are mateed together through a turntable, allowing the ipper to swing from side to side. These modern hydraulic truck cranes are usuallt single-engine nachines, with the same engine powering the undercarriage and the crane. The upper is usually powered via hydraulics run through the turnable from the pump mounted on the lower. In older model designed of hydraulic truck cranes, there were two engines. One in the lower pulled the cranedown the road and ran a hydraulic pump for the outrrigers and jacks. The one in the upper ran the upper through a hydraulic pump of its own. Many older operators favor the two-engine system due to leaking seals in the turnable of aging newer design cranes.



    If you're interested in our turck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995



    More pictures of Dongfeng jincheng 8tons telescopic crane boom mounted on truck as below.

    HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale

    HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale

    HOT SALE!DONGFENG JINCHENG 4*2 LHD yuchai 180hp diesel 8tons telescopic crane boom mounted on truck for sale

    The specification of dongfeng 4*2 LHD 8tons telescopic crane boom mounted on truck for sale

    Product name Dongfeng brand 4*2 LHD 8tons telescopic crane boom mounted on truck for sale
    Chassis type EQ1180GSZ5DJ
    Parameters Overall dimension length/width/height (mm) 9000×2400,2500×3650,3850
    Cargo body dimension (L*W*H)(mm) ,5800,6100×2300,2400×550
    GVW(kg) 18000(Kg)
    Kerb Mass(kg) 9800(Kg)
    Rated mass(kg) 8005(Kg)
    Approach angle/ Departure angle(mm) 23/19 (°)
    Front suspension/rear suspension(mm) 1515/2385
    Fuel Type diesel
    Max Speed 90
    Engine Type YC6JA180-50
    Displacement/Power(kw) 4260ml/118KW/180hp
    Manufacturer Yuchai
    Chassis Drive Type 4×2
    Wheelbase(mm) 5100
    Tread(front/rear) 1940/1860 (mm)
    Transmission 8 speed gearbox, manual
    Braking system Air braking
    Number of spring axle(front/rear) ,8/10+8
    Tire Type 10.00R20 18PR * 6+1
    Air-condition Choose to install
    Upper part(cargo van and crane boom) main parameters
    Upper body Cargo body dimension 5800/6100*2295*550mm
    Material Carbon steel
    Side sheet thickness 2mm thickness
    Bottom sheet thickness 2mm thickness
    Painting Upon request
    Crane boom main parameters
    Crane boom Choose to install CLW brand 8tons 4/5 sections telescopic crane boom
    Crane boom lifting height 15.5m/18.5m
    Crane boom working radius 13.5m/16.5m
    Rotation Full hydraulic, full rotation
    The color of the whole truck is upon request.
