ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane

ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane

    • ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane
    • ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane
    • ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane
    • ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane
  • ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane

    Product Details:

    Place of Origin: China
    Brand Name: CLW
    Certification: CCC, ISO 9001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package, waxed
    Delivery Time: 20 days
    Payment Terms: T/T, L/C
    Supply Ability: 20units/month
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request, Free To Paint Company Logo Price: High Quality Factory Direct Sale Price
    Truck Chassis: China Made ISUZU Diesel Truck Chassis Crane Boom: CLW Brand/XCMG Brand 4tons Telescopic/knuckle Crane Boom





    HOT SALE! ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality and competitive price ISUZU 4T telescopic cargo truck with crane



    Customized truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.

    As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.



    If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995



    ISUZU 700P 4T truck with crane adopts ISUZU brand 700P 4*2 LHD truck chassis, 4475mm wheelbase, ISUZU MLD 6 speed manual gearbox, ISUZU 4HK1-TCG40 190hp Euro 4 diesel engine, 4tons front axle/7tons rear axle, 8.25-16/8.25R15 tires, ISUZU 700P single row luxurious driver cab with power steering and air conditioner, etc.



    The overall dimension (L*W*H) of ISUZU 4T telescopic crane boom mounted on truck is 7950×2307×3100(mm), and the cargo body box dimension (L*W*H): 5360×2150×450(mm). Client chooses to install CLW Brand high quality 4tons telescopic /knuckle crane boom.

    ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane

    HOT SALE! ISUZU Brand 700P 4tons telescopic crane boom mounted on truck

    ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane

    high quality and competitive price ISUZU 4tons telescopic cargo truck with crane for sale

    ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane

    The specification of ISUZU brand 4*2 700P 4tons telescopic crane boom mounted on truck as below.

    Product name ISUZU 4*2 LHD 4T telescopic crane mounted on truck for sale
    Chassis type QL11009MARY
    Parameters Overall dimension length/width/height (mm) 7950×2307×3100(mm
    Cargo body dimension (L*W*H)(mm) 5360×2150×450
    GVW(kg) 10000(Kg)
    Kerb Mass(kg) 5150 (Kg)
    Rated mass(kg) 4655(Kg)
    Approach angle/ Departure angle(mm) 20/10 (°)
    Front suspension/rear suspension(mm) 1110/2365 (mm)
    Fuel Type diesel
    Max Speed 110
    Engine Type 4HK1-TCG40
    Displacement/Power(kw) 5193ml/139KW/190hp
    Manufacturer Isuzu
    Chassis Drive Type 4×2
    Wheelbase(mm) 4475
    Tread(front/rear) 1680/1650 (mm)
    Transmission ISUZU MLD 6 speed gearbox, manual
    Braking system Air braking
    Cab ISUZU brand 700P single row driver cab
    Number of spring axle(front/rear) 8/10+6
    Tire Type 8.25-16/8.25R15 tires
    Upper part(cargo van and crane boom) main parameters
    Upper body Cargo body dimension 5360×2150×450(mm)
    Material Carbon steel
    Side sheet thickness 2mm thickness
    Bottom sheet thickness 2mm thickness
    Painting Upon request
    Crane boom main parameters
    Crane boom Choose to install CLW brand 4tons 4sections telescopic crane boom
    Lifting height 13m
    Working radius 11m
    Aerial operation seat Yes
    Hydraulic operation Yes, full hydraulic operation
    Full rotation Yes, full rotation
    The color of the whole truck is upon request.

    CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.



    Chengli Special Automobile Co., Ltd. is the leading manufacturer of truck with crane, truck mounted crane, dump truck with crane, cargo truck with crane, telescopic crane mounted on truck, etc. With many years’ experience in manufacturing, Chengli Special Automobile Co., Ltd. could manufacture and supply 4*2 small truck with crane, 4*4 truck with crane, 6*2 dump truck with crane, 6*4 cargo truck with crane, 8*4 crane monted on truck, etc. And the CLW brand cranes are from 2.5ton to 20 ton, and much bigger for different trucks. Chengli Special Automobile Co., Ltd. coulkd design and produce the trucks according to customers’ requirements. More information, please feel free to contact with us.

    Whatsapp/Wechat/Mob.:+86 13329899995

    Email: truck0011@163.com; anitadeng1027@hotmail.com

    QQ: 504873236
