hot sale CLW brand 59.53cbm New lpg transport trailer / new lpg transport truck tanks/lpg transport tank semi trailer for sale
Lpg transporting trailer , is also called LPG trailer , LPG tank semitrailer , is widely used in transporting kinds of Liquefied petroleum gas, such as propane, isobutane, propylene, dimethyl ether, ammonia, etc. Adopt China newest or USA ASME pressure vessel Standard, it is high quality and reliable safety.
Chengli Special Automobile Co., Ltd. is a famous professional LPG tank manufacturer in China,and also is the earliest engaged in PRESSURE VESSEL production-manufacturing in Suizhou city,which known as the SPEICAL AUTOMOBILE CAPTIAL OF CHINA,we specialize in this field for several years with good quality and reasonable price.Our registered label CLW is a famous trademark in China. Our products fully passed and 3C authentication.
1,We have the biggest LPG truck in China,and the valid volume is 35.5CBM.
2,We have the biggest LPG semi-trailer in China,and the valid volume is 60CBM, low transportation cost,bring more profit.
3,We can also provide LPG storage tank ranged from 5CBM to 120CBM,both on the floor ones and in the ground ones.
Cheng Li functional characteristics of liquefied petroleum gas tank:
1, pressure components of the product materials, dimensions and weld quality, operation quality, installation quality,safety devices and accessories within the strict qualification
2, conventional tank materials on physical and chemical tests such as: mechanical properties and chemical composition.Their welded joints, weld, tank head, the pressure of the geometric location of each component through rigorous X-ray non- destructive testing and magnetic particle testing inspection.
3, seal on the product, pressure, and those who can affect the operation of product safety testing various technical indicators.
4, A,B Class 100% ray weld inspection, II level qualified, C, D Class welds 100% magnetic particle inspection, I level qualified.
If you're interested in our lpg gas tanker trailer, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of CLW brand 59.53cbm lpg gas tanker trailer manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! best price CLW brand 60cbm bulk lpg gas tanker trailer for sale
High quality and competitive price CLW Brand 59.53cbm bulk road transported lpg gas tanker for sale
Features of CLW brand 60cbm lpg gas tanker trailer manufactured by Chengli Special Automobile Co., Ltd. as below.
1.high quality and factory price fuel tank semi trailer,oil tanker truck traielr for sale
2.ASME standard or China standard to be optional
3.Q345R tank material,massive, durable, long service life
4.Fuwa or BPW axle for your choice
5.JOSTkingpin
| LPG storage tank |
| Model |
CLW9408GYQB |
| Overall dimension |
Approx 13000*2500*3990(mm) |
| GVW/curb weight |
4000kg/15000kg |
| Tank volume |
59.53CBM |
| Tank size(length*thickness*inner diameter) |
12791*11*2478mm |
| Tank material |
Q345R |
| Filling gas |
LPG (propane) |
| End cover form |
Ball or Ellipse |
| Design Specific Gravity |
0.42 -0.545Kg/L |
| design temperature |
50 0C |
| working temperature |
-20~50 0C |
| Corrosion allowance |
1.0 mm |
| design pressure |
1.61 MPa |
| Running mechanism |
| Frame |
Material |
Q235 carbon steel |
| Axle |
Brand |
BPW |
| Type |
13T |
| Number |
3 pcs |
| Tyre |
Type |
12R22.5 tubeless |
| Number |
13pcs |
| Suspension |
Leaf spring,-/7/7/7 |
| King pin |
Type |
Bolts type |
| Diameter |
90mm |
| Brake system |
Type |
Air brake |
| Brake chamber |
6 double Spring brake chamber |
| ABS |
YES |
| Landing gear |
Brand |
JOST brand |
| Capacity |
28T standard |
| Other standard accessories |
Valve box,tool box,drain hole,emergency cut-off valve,safety valve, indicator for liquid level,thermometer,pressure gauge |
This parameter is just for your referance, we can produce different specification lpg tank semi
trailer according to your demand.
