Customized high quality and best price dayun brand new 4*2 LHD 2tons truck with crane for sale, HOT SALE! cargo truck with crane
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
Chengli Special Autmobile is the leading manufacturer and supplier of truck with crane in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply cargo truck with crane, dump truck mounted crane, crane truck, etc. More information, please feel free to contact with Ms. Anita.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wecgat/Mob.: +86 13329899995.
more pictures of DAYUN brand 2tons cargo truck with crane as below
Hot sale Dayun Brand 4*2 LHD 2tons cargo truck with crane, adopts high quality DAYUN yuntu 1880mm single row driver cab, 3300mm wheelbase, wangliyang 5 speed manual gearbox, 825R16 rail tires, etc.,
And the cargo body box dimension of DAYUN 2tons telescopic crane boom mounted on truck is 3200,3400,3500×2100,2200,2300×400,550(mm), while the overall dimension of the dayun 2tons truck with crane is 5995×2250,2400,2500×2980,3300,3460. Client chooses to install CLW brand 2tons telescopic crane boom.
The specification of SINO TRUK DAYUN 2tons telescopic crane boom mounted on truck as below
| Product name |
DAYUN Brand 4*2 LHD 2tons telescopic crane boom mounted on truck for sale |
| Truck chassis |
DYQ1041D5AA |
| Parameters |
Overall dimension length/width/height (mm) |
5995×2250,2400,2500×2980,3300,3460 (mm) |
| Cargo body dimension (L*W*H)(mm) |
3200,3400,3500×2100,2200,2300×400,550 (mm) |
| GVW(kg) |
4495 (Kg) |
| curb Mass(kg) |
3160 (Kg) |
| Rated mass(kg) |
1140 (Kg) |
| Approach angle/ Departure angle(mm) |
17/19(°) |
| Front suspension/rear suspension(mm) |
1300/1395 (mm) |
| Fuel Type |
diesel |
| Max Speed |
80 |
| Engine |
Type |
YC4FA120-50 |
| Displacement/Power(kw) |
2982ml/88KW/120hp; |
| Manufacturer |
Yuchai engine; |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
3300 |
| Tread(front/rear) |
1565/1630 |
| Transmission |
5 speed manual gearbox |
| Braking system |
Air braking |
| Cab |
1880mm single row driver cab |
| Number of spring axle(front/rear) |
9/9+6 |
| Tire Type |
825R16 |
| Air-condition |
Choose to fix |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
3200,3400,3500×2100,2200,2300×400,550 (mm) |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 2ton telescopic boom |
| Max lifting mass |
2000kgs |
| Sections |
2/3 |
| Working radius |
5m/7m |
| Lifting height |
7m/9m |
| Rotation degree |
±360°full rotation, full hydraulic |
