Chengli Special Autmobile is the leading manufacturer and supplier of truck with crane in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply cargo truck with crane, dump truck mounted crane, crane truck, etc. More information, please feel free to contact with Ms. Anita.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of DAYUN brand 5tons telescopic crane boom mounted on truck as below
DAYUN brand 4*2 LHD diesel 5tons truck with crane, adopts dayun 2080mm one row and a half driver cab, 3900mm wheelbase, 6 speed gearbox, 9tons rear axle, 8.25R20 16P or 9.00-20 14PR* 6+1, YN38CRE1 YUNNEI 130hp diesel engine, etc.
The dimension of cargo body box is 4300,×2100,2200,2300×550,600 (mm); while the overall dimension of dongfeng T5 12tons telescopic crane mounted on truck is 7280×2400,2500×3560(mm). Clients choose to install CLW Brand high quality 5tons telescopic crane boom.
Main technical parameters of DAYUN brand 5tons telescopic crane boom mounted on truck as below
| Product name |
DAYUN brand 5tons telescopic crane boom mounted on truck for sale |
| Chassis type |
DYQ1121D5AA |
| Parameters |
Overall dimension length/width/height (mm) |
7280×2400,2500×3560(mm) |
| Cargo body dimension (L*W*H)(mm) |
4300,×2100,2200,2300×550,600(mm) |
| GVW(kg) |
11995(Kg) |
| Kerb Mass(kg) |
7300 (Kg) |
| Rated mass(kg) |
4500 (Kg) |
| Approach angle/ Departure angle(mm) |
25/22 (°) |
| Front suspension/rear suspension(mm) |
1300/2080 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
YN38CRE1 |
| Displacement |
3760ml |
| Rated power |
95KW/130Hp |
| Manufacturer |
Yunnei |
| Chassis |
Drive Type |
4*2 LHD |
| Wheelbase(mm) |
3900 |
| Tread(front/rear) |
1940/1860 (mm) |
| Transmission |
6 speed gearbox, manual |
| Braking system |
Air braking |
| Number of spring axle(front/rear) |
9/11+8 |
| Tire Type |
9.00-20/825R20 |
| Air-condition |
Choose to install |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
8500×2300×550(mm) |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 5tons telescopic crane boom |
| Rotation |
Full hydraulic, full rotation |
| The color of the whole truck is upon request. |
