|Place of Origin:||China|
|Certification:||CCC, ISO 9001|
|Minimum Order Quantity:||1 unit|
|Packaging Details:||in bulk package, waxed|
|Delivery Time:||20 days|
|Payment Terms:||T/T, L/C|
|Color:||Different Color Upon Request, Free To Paint Company Logo||Price:||High Quality Factory Direct Sale Price|
|Material:||High Quality Carbon Steel Material||Truck Chassis:||China Made High Quality JMC Brand Diesel Truck Chassis|
HOT SALE! JMC single row 116hp diesel 2tons telescopic crane boom mounted on truck, High quality and competitive price JMC truck with crane for sale
Chengli Special Autmobile is the leading manufacturer and supplier of truck with crane in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply cargo truck with crane, dump truck mounted crane, crane truck, etc. As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.More information, please feel free to contact with Ms. Anita.
JMC brand 4*2 LHD truck with crane adopts JMC single row driver cab, 3360mm wheelbase, 2tons front axle/ 3.5tons rear axle, 7.00R16 rail tires, 5 speed gearbox, JX493ZLQ5 85KW 116hp Euro 5 diesel engine, etc.
The overall dimension of JMC Brand 4*2 LHD 2tons telescopic crane boom with truck is 5995×2065×2900(mm), and the cargo body dimension of JMC Brand telescopic crane boom mounted on truck is 3590×1850×380 (mm).Client choose to install CLW Brand 2tons telescopic crane boom.
If you're interested in our truck with crane, please send email to firstname.lastname@example.org or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
The pictures of JMC brand single row 2tons telescopic truck with crane manufactured by Chengli Special Automobile Co., Ltd. as below.
The specification of JMC 2tons telescopic crane boom mounted on truck as below
|Product name||JMC Brand 2tons telescopic crane boom mounted on truck|
|Parameters||Overall dimension length/width/height (mm)||5995×2065×2900(mm)|
|Cargo body dimension (L*W*H)(mm)||3590×1850×380 (mm)|
|curb Mass(kg)||3140,2800 (Kg)|
|Rated mass(kg)||1225,1565 (Kg)|
|Approach angle/ Departure angle(mm)||27/14.7 (°)|
|Front suspension/rear suspension(mm)||1065/1570 (mm)|
|Transmission||5 speed transmission, manual|
|Braking system||Oil cut braking|
|Cab||JMC double cab driver cab|
|Number of spring axle(front/rear)||7/4+6,7/5+6|
|Tire Type||7.00R16 rail tires|
|Air-condition||Choose to fix|
|Upper part(cargo van and crane boom) main parameters|
|Upper body||Cargo body dimension||2700×1800×380 (mm)|
|Side sheet thickness||2mm thickness|
|Bottom sheet thickness||2mm thickness|
|Crane boom main parameters|
|Crane boom||Choose to install CLW brand 2ton telescopic/knuckle boom|
|Rotation degree||±360°full rotation, full hydraulic|
