Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl ether, methanol, butadiene, butane, ethylene oxide, methylamine, etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 120 cubic optional. Besides, the lpg gas tank, Chengli Special Automobile Co., Ltd. could offer lpg gas trailer, lpg gas delivery truck, lpg gas dispenser vehicle, skid lpg gas filling plant, etc. More information, please feel free to contact with Ms. Anita Deng.
The technical advantages of CLW brand lpg gas pressuree vessels manufactured by Chengli Special Automobile Co., Ltd.
1. Anti-corrosion coating the surface .Using sand-blasting treatment, spraying, blowing, and other advanced technology.
2.High-quality home-made or imported Safety Accessories for users matching, fully furnished.
3.Strictly to science and the advanced construction technology to ensure that at low temperatures, the contraction rate of the highest dimensional stability.
4. rigorous quality testing: A, B Class 100% seam-ray testing, II level qualified C, D Class weld 100% magnetic particle inspection, I level qualified.
Tank shaped use the advanced welding technology, end socket arc butt welding, and the once-forming of composite steel-plastic technology. Equipped with active and passive safety devices to meet an emergency and can load and unload the material in long distance and completely close condition. Be applied to transport natural gas, liquefied petroleum gas, liquefied ammonia, carbon bisulfide, epoxy ethane, gas, butane, dimethylmethane, propylene, etc. Cross section of tank could be oval, round and round-square. heat insulation and heating device is optional.
Natural gas in normal temperature with low or medium pressure.
Tank volume various from 5 Cubic-200 cubic meters.
Our company has solid technology, flawless inspection, advanced equipments, reliant quality and flexible modes of operation. What’s more, it has roundly passed the ASME standard;ISO9001,the 3C(China Compulsory Certification) and BV factory audit.
If you're interested in our lpg gas pressure vessels, please kindly send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/MOb.: +86 13329899995.
More pictures of hot sale lpg gas tanks manufactured by Chengli Special Automobile Co., Ltd. as below.
the specification of CLW Brand 50tons bulk lpg gas storage tanker manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items |
Unit |
Main parameters |
| Product name |
|
LPG gas storage tank(120cbm) |
| Product model |
|
CLG3400-120 |
| Loading medium |
|
LPG (propane) |
| Overall dimension(L*W*H) |
mm |
13820*3436*4026 |
| Tank dimension(inner diameter*thickness*length) |
mm |
DN3400*18*13,820 |
| Tank volume |
m3 |
120cbm |
| Curb mass |
kg |
24960 |
| Loading capacity |
Kg |
60,000 |
| Designed pressure |
Mpa |
1.77 |
| Working pressure |
Mpa |
≤1.6 |
| Working temperature |
oc |
≤50 |
| Hydraulic test pressure |
Mpa |
2.22 |
| Medium specific gravity |
Kg/cbm |
About 0.5kg/cbm |
| Air tight test pressure |
Mpa |
1.77 |
| Tank and main Material pressure components |
Q345R,16Mnlll |
| Chosen safety accessories |
Safety valves, magic level gauge, pressure gauge, temperature gauge, cut-off valves, etc.
|
| Standard |
<<GB150steel pressure vessel>>,<<Supervision Regulation on Safety Technology for Pressure Vessel>>
|
