A crane mounted on a truck carrier provides the mobility for this type of crane. This crane has two parts: the carrier, often referred to as the Lower, and the lifting component which includes the boom, referred to as the Upper. These are mated together through a turntable, allowing the upper to swing from side to side. These modern hydraulic truck cranes are usually single-engine machines, with the same engine powering the undercarriage and the crane. The upper is usually powered via hydraulics run through the turntable from the pump mounted on the lower. In older model designs of hydraulic truck cranes, there were two engines. One in the lower pulled the crane down the road and ran a hydraulic pump for the outriggers and jacks. The one in the upper ran the upper through a hydraulic pump of its own. Many older operators favor the two-engine system due to leaking seals in the turntable of aging newer design cranes.
As a professional truck mounted crane manufacturer in China, the crane we manufacture is from 2 ton to 160 ton. The drive type of our truck crane for sale are 4x2, 6x2, 6x4,8x4,etc. The crane truck for sale are telescopic boom crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane of crane truck can be UNIC crane, chengli crane truck, sany, etc.
If you're interested in our CLW brand truck with crane, please kindly send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of CLW brand truck with crane manufactured by Chengli Special Automobile Co., Ltd. as below.
main technical parameters of CLW brand truck with crane manufactured by Chengli SPecial Automobile Co., Ltd. as below.
| TRUCK MOUNTED CRANE |
| # |
Descriptions |
Specifications and types |
| General |
Truck Brand |
Chengliwei (our brand) |
| Chassis Brand |
Foton |
| Approx. Dimension |
5995*2050*2820 mm |
| GVW./Kerb Wt. |
4495/ 2925kg |
| Cab |
Cab Capacity |
2 persons' seat |
| Air Conditioner |
Air Conditioner is optional |
| Chassis |
Drive Type |
4X2,left hand drive |
| Fuel Type |
Diesel |
| Engine Make & Model |
foton engine |
| Power |
108hp |
| Emission Standard |
Euro II or EURO III |
| Brake |
Air Brake |
| Wheelbase/No.of axle |
3300 mm / 2 |
| Tyre Specfication |
7.00-16 8PR |
| Tyre Number |
6 tyres and 1 spare tyre |
| Max Speed |
80 km/h |
| Paint |
Automative metallic paint |
| Cargo box |
Cargo body dimension |
3400*1880*400 mm |
| Crane |
Max Lifting Capacity |
2000kg |
| Crane Weight |
650kg |
| Rotation Angle |
360 all rotation |
| Installation Space |
850-1150mm |
| Structure& Function |
Telescopic/Articulated boom crane loading weight:2T,3.2T,4T,5T,6.3T,8T,10T,12T,14T,16T,20T 25T or others
Truck Cargo length: 3m-13m.
Crane Installation Site: Rear or Middle part
2 ton knuckle crane max lifting height 6.8m working radius 6m
|
The above information is for reference only. We can produce according to your needs so, If you have any questions you can contact me at any time.
