Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years'development, Chengli Special Automobile Co., Ltd. could manufacture and supply surface/underground lpg gas storage tank, lpg gas tank semitrailer, skid lpg gas refilling plant, lpg gas truck, lpg gas bobtail vehicle, etc. More information, please feel free to contact with Ms. Anita.
Skid LPG gas filling station, is mainly used to build a gas filling station for retailing and selling LPG gas in a city, for kitchen use gas cylinder, it is euipped with big LPG storage tank, pipe system, safety accessroies, gas filling scales(can install many scales at the same time), etc. At present, we Chengli Special Automobile Co., Ltd. can design and manufacture skid lpg gas refilling stations from 5m3 to 50m3,even customized bigger ones. Meanwhile, we can also manufacture and sell CKD/SKD for skid lpg gas refilling stations. Clients can purchase our surface lpg gas storage tanks and the CKD/SKD accessories, then to install the skid lpg gas refilling plant locally by themselves.
Nowadays, more and more clients choose to purchase mobile skid lpg gas plant for their lpg gas plant business. We Chengli Special Automobile Co., Ltd. can customize skid lpg gas plant with digital scales for filling domestic gas cylinders or automatic lpg gas dispenser for automobiles or gas cylinders. The lpg gas dispensing machine is with single filling gun or double filling guns for filling single gas cylinders or double gas cylinders at one time.
If you're interested in our skid lpg gas refilling station, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of mobile skid lpg gas refilling station with electronic scale as below.
main technical parameters of skid lpg gas refilling station as below.
|
Technical Specification
|
Parameter
|
|
Tank
|
Tank name
|
LPG storage tank
|
|
Model
|
CLW2300-50
|
|
Overall dimensions
|
12508*2324*2914 mm
|
|
Inner diameter
|
2300mm
|
|
Vessel type
|
on the ground
|
|
Designing pressure
|
1.77 Mpa
|
|
Working pressure
|
1.61 Mpa
|
|
Designing temperature
|
-19~50
|
|
Filling medium
|
Liquid petroleum/propane gas
|
|
Corrosion margin
|
1.00 mm
|
|
Curb weight
|
19950kg
|
|
Full capacity
|
50m³
|
|
Heat treatment
|
Bulk
|
|
Filling factor
|
420 Kg/ m³
|
|
Tanker & pressure parts material
|
Q345R
|
|
Hydraulic test pressure
|
2.22 Mpa
|
|
Gas tight test pressure
|
1.77 Mpa
|
|
Produce standard
|
ASME standard and GB150 standard
|
|
Optional accessories
|
afety valve,SCL-UHZ(magnetic flap gauge),pressure gauge,thermometer,cut-off valve etc.
|
|
Liquid indicator
|
Model
|
UHZ-518C14
|
|
Version
|
Magnetic
|
|
Nominal pressure
|
2.5 Mpa
|
|
Scope of testing
|
50~2500 mm
|
|
precision
|
2.5
|
|
Safety Valve
|
Model
|
A42F-2.5-80
|
|
Version
|
Built-in
|
|
Nominal pressure
|
2.5 Mpa
|
|
Nominal radius
|
DN80
|
|
Opening pressure
|
1.68-1.76 Mpa
|
|
Re-seating pressure
|
≥0.8 Mpa opening pressure
|
|
Handling System
|
Feed pipe
|
DN80
|
|
Drain pipe
|
DN80
|
|
Admission port
|
DN50
|
|
Sewage outfall port
|
DN80
|
|
Vent nozzle port
|
DN80
|
