Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years’ development, Chengli Special Automobile Co., Ltd. could offer bulk surface lpg gas storage tank, underground lpg gas storage tank, lpg gas trailer, lpg gas delivery truck, lpg gas dispensing truck, mobile skid-mounted lpg gas filling station, etc. More information, please feel free to contact with Ms. Anita. The hot sale line is 0086 13886878855.
The LPG Skid-Mounted station has the following functions manufactured by Chengli Special Automobile Co., Ltd. as below.
*Feeding gas to gas vehicles: high quality dispenser is equipped and its measurement is accurate and stable.
*Unloading: The LPG tank car can unload the medium to the storage tank on the skid-mounted plant smoothly
*Drainage: The sundries like water-logging in the storage tank will e drained through the drain outlet.
*Emptying:The residual pressure in storage tank can be released through the emptying port during overgauling.
*Alternative Pumps: Under fault condition, gas filling pump and unloading pump can be mutually alternative.
*Reverse unloading:The liquid on the storage tank can be unloaded to the gas tank car and delivered.
*Emergency cut-off :Air-operated emergency cut-off valve is installed a the liquid outlet on the storage tank, by which the emergency cut-off under abnormal conditions can be achieved.
*Leakage Alarm: Leakage probes are installed in the key positons of the skid-mounted gas station, so as to dect the equipment's security status.
*LIquid Level Alarm: Upper and lower liquid level limit switch are installed. Therefore, it has liquid alarm and control function.
If you're interested in our lpg gas pressure vessel, please send email to truck0011@163.com; or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of CLW brand 20cbm skid lpg gas refilling station with double electric filling scales as below.
One unit of CLW brand 20cbm skid lpg gas refilling station with double electric filling scales customized for overseas client is finished. Look at the finished pictures of CLW brand 20cbm skid lpg gas refilling station with double electronic filling scales as below.
| Item |
Model |
Unit |
No. |
Remark |
| Lpg gas storage tank |
20,000Liters |
Piece |
1 |
Standard skid with low frame base (for 40’ container) |
| Hydrocarbon pump |
YQB15-5 |
Piece |
1 |
Driving belt with cover,pump base |
| Explosion-proof three-phase asynchronous motor |
5.5KW |
Piece |
1 |
| Concentration alarm |
- |
Piece |
1 |
|
| Digital filling scale |
China made |
Piece |
2 |
|
| Explosion-proof control box |
- |
Piece |
1 |
|
| Floating ball level meter |
UQZ-6 |
Piece |
1 |
|
| Temperature gauge |
M33*1.5 1.5 grade 0～4mpa |
Piece |
2 |
|
| Safety valve |
DN50 |
Piece |
1 |
|
| Globe valve |
DN50 |
Piece |
1 |
| Safety backflow valve |
AH42F-25 DN25 |
Piece |
1 |
|
| Y-Strainer |
GL41H-25 DN50 |
Piece |
2 |
|
| Globe valve |
J41W-40 DN50 |
Piece |
5 |
|
| Ball valve/check |
Q41F-40 DN50 |
Piece |
5 |
|
| Discharging pipe |
L=4m DN50 |
Piece |
2 |
|
| check valve |
M42N-25 DN50 |
Piece |
1 |
|
| Sprinkling |
|
Piece |
1 |
Galvanized tube |
| Needle valve |
DN6 |
Piece |
3 |
|
| Ball valve |
DN15 |
Piece |
1 |
|
| damper tube |
- |
Piece |
1 |
|
The product features of electronic filling scale for skid lpg gas refilling station manufactured by Chengli Special Automobile Co., Ltd. as below
1, the grand scale integration is applied in the master board of the system so that it is very high in reliability and stability, with ultra-high brightness long-life nixie tube display, clear and precise in readings.
2, the four modes of filling can be set, such as net weight filling, total weight filling, complex filling and accounting filling.
3, there are 8 sets of filling quantities, meanwhile, the set “0” can be used to the arbitrary filling.
4, when the filling is completed, the visible and audible alarms will be sent; meanwhile, the normal filling and abnormal filling can be differentiated.
5, the weight inspection in filling can be carried out one time, without additional inspection balance, with overfilling alarm and automatic filling function if weight missing.
6, the 3500 filling records can be totaled and stored, including filling date, filling time, filling weight, steel bottle weight, actual filling weight, error weight, job code and customer code, etc.
7, the cumulative enquiry in every shift, total cumulative enquiry and arbitrary filling record enquiry can be realized.
8, having the functions of keyboard locking, power off protection, shockproof, resistance to impact and electromagnetic interference.
9, with the computer communication interface(RS485 interface), it can be interconnected with the computer to process data and monitor filling and implement the efficient management of data.
10, the full filling range can be calibrated automatically via the set of weights and keys so that the operation is very easy.
11, if below the lower limit of the empty bottle or over the upper filling limit, the filling will be forbidden to avoid accident overfilling.
12, the scale is reasonable in structure design, easy in maintenance.
13, equipped with the clock display and metering shielding function.
14, for the large-scale customers, the filling in batches can be applicable.
15, the lead filling function can be set by the user to ensure the filling precision.
