new face dongfeng D9 18m-22m hydraulic aerial working platform truck for sale, Customized best price overhead working truck for sale
The technical advantages of CLW brand D9 high altitude operation truck as below.
1. Aerial platform vehicles is also named high-altitude operation truck, refers to the special vehicles for aerial operation with the delivery of staff and the equipment to the scene.
2. We are professional factory, supply Dongfeng aerial vehicles, JMC aerial working vehicles, JAC aerial platform vehicles, Qingling high-altitude working truck, Foton aerial platform operating vehicles, etc., working height of 8-24 meters for choose.
3. Produced by the high-altitude operation vehicles, using double lift hydraulic cylinder, up and down a total of four hydraulic cylinders, the conventional aerial vehicles only two lifting cylinders, double lift hydraulic cylinder in the lift, rotation process does not tremble, do not shake, stability Sex, safety is better.
4. High-altitude operation vehicles using domestic or imported reversing valve and hydraulic cylinder, for the balance, flexible and convenient operation, outrigger and work arm interlocking, outrigger and work arm interlock to prevent misuse over.
5. Installed four hydraulic legs, to ensure vehicle stability and safety in operation.
6. Optional aerial crane hook, hook hanging 1 ton and the electronic control system.
7. Aerial platform vehicles can be up and down operation, 360-degree rotation, install the hand throttle.
8. If you have any special requirements for the aerial vehicles, please let us know, we can design for you.
If you're interested in our aerial working platform truck, please feel free to send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
More pictures of CLW brand high altitude operation truck as below.
Technical specifications of CLW brand new face D9 aerial platform truck as below.
| Item |
Unit |
Parameter |
| Vehicle model |
|
Dongfeng Aerial Platform Truck CLW5112JGKD5 |
| Chassis model |
|
EQ1161LJ9BDE |
| Overall dimensions |
mm |
10100×2500×3800 |
| Gross weight |
kg |
10705 |
| Curb weight |
kg |
10510 |
| Wheel base |
mm |
4500 |
| F/R track base |
mm |
1858/1806 |
| Approach/departure angle |
° |
19/10 |
| Exhaust |
ml/kw |
4730/125 |
| Max speed |
km/h |
90 |
| Tire specification |
|
9.00R20 |
| Engine type |
|
YC4EG170-50 |
| Engine manufacturer |
|
Guangxi Yuchai Machinery CO.,LTD |
| Traction system |
|
4×2 |
| transmission |
|
5-speed with over drive |
| Pieces of springs |
|
8/10+7 |
| Electric system |
|
24v |
| Operation control system |
|
Electrically hydraulic control |
| Allowable pax in cab |
|
3 |
| Equipment |
1.The operation height is 22m. With 3 working arm uploading, the height is 20m.
2.The rear stretching is 700mm. Front extension/wheel base: 620/4700, 820/4500
3.Protective material: Q235A carbon steel. Connection mode: the right and left side and the rear are all welded for protection. The rear protection section size (mm) : 180 x 50; the rear protection clearance height (mm) : 480
4.ABS model: J ABS. Manufacturer: Jiaozuo Borrik Control Technology co. LTD
5.The position of the text and the color of the vehicle can be changed.
6.Optional tires of 9.00 R20 16PR and 10.00 R20 14/16/18PR specifications.
|
| Production cycle |
15-20 working days after deposit |
| FOB Shanghai |
USD |
