LPG skid filling station is widely used in storing LPG, Liquid ammonia, Propane and other liquefied petroleum gas. We can supply LPG Tanker from 5m3 to 200 m3.
1. Factory direct supply LPG/propane tank, past ISO&3C, hot selling in both China and abroad
2. More than 10 years on the line of manufacturing LPG/propane/oil tank, professional in this field
3. Different volume for clients' choice, can design based on customers' reqirement
4. Q345R or Q370R tank material, high quality with competitive price
5. Strictly perform newest China pressure vessel standard: GB150-2011, with BV Certification and ASME certification.
If you're interested in our skid lpg gas refilling station, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob. : +86 13329899995.
More pictures of 50cbm skid lpg gas refilling station as below.
Technical Specifications of 50cbm 20tons skid lpg gas refilling station as below.
| Volume of Tank (cbm) |
50 |
| Mass of Tank |
15300 |
| Filling Mass |
20832 |
| Thickness of Shell (mm) |
12 |
| Thickness of Endplate (mm) |
14 |
| Diameter (mm) |
2300 |
| Overall Dimensions (mm) (length X width X height) |
12740x2480x3800 |
| Material of Tank & main Pressure parts |
Q345R carbon steel |
| Filling Medium |
Liquefied Petroleum Gas |
| Design Pressure |
1.61MPa |
| Corrosion Allowance |
1mm |
| Medium Density |
420kg/cbm |
| Service Time |
15 Year |
| Gas pump power |
5.5KW |
| Pump flow |
15.5m3/h |
| Manufacturing Standard |
GB150-2011 |
| Carried Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels. |
| Safety Valve of Selection Fitting: Safety valve, Column magnetic reversible level meter, Pressure gauge, Thermometer, Cut-off valve. |
We can supply double axle or tri-axle and different capacities LPG tank according to different demands. We use high quality Q345R material to ensure these product's stability, safety and large capacity during transportation. Please feel free to contact me for more details.
skid system lpg with automobile lpg dispenser can fill not only the domestic gas cylinders, but also automobiles, mainly city buses, just to adjust the nozzles.
Nowadays, more and more clients choose to purchase mobile skid lpg gas plant for their lpg gas plant business. We Chengli Special Automobile Co., Ltd. can customize skid lpg gas plant with digital scales for filling domestic gas cylinders or automatic lpg gas dispenser for automobiles or gas cylinders. The lpg gas dispensing machine is with single filling gun or double filling guns for filling single gas cylinders or double gas cylinders at one time.
