Place of Origin: | China |
Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request, Free To Paint Company Logo | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Material: | High Quality Q345R Material For Lpg Gas Pressure Vessels | Volume: | 5cbm,8cbm,10cbm,12cbm,15cbm, 20cbm, 25cbm, 32cbm, 40cbm, 45cbm, 50cbm |
Supply any size LPG tanker station mobile Lpg gas cylinder station price sale, HOT SALE! China supplier of skid lpg gas refilling station for gas cylinders
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years'development, Chengli Special Automobile Co., Ltd. could manufacture and supply surface/underground lpg gas storage tank, lpg gas tank semitrailer, skid lpg gas refilling plant, lpg gas truck, lpg gas bobtail vehicle, etc. More information, please feel free to contact with Ms. Anita.
Skid LPG gas filling station, is mainly used to build a gas filling station for retailing and selling LPG gas in a city, for kitchen use gas cylinder, it is euipped with big LPG storage tank, pipe system, safety accessroies, gas filling scales(can install many scales at the same time), etc. At present, we Chengli Special Automobile Co., Ltd. can design and manufacture skid lpg gas refilling stations from 5m3 to 50m3,even customized bigger ones. Meanwhile, we can also manufacture and sell CKD/SKD for skid lpg gas refilling stations. Clients can purchase our surface lpg gas storage tanks and the CKD/SKD accessories, then to install the skid lpg gas refilling plant locally by themselves.
LPG,liquid pressure gas,which is made from oil.The main gas is propane,Isobutane.
Currently our company produce the lpg tank, lpg tank trailer,lpg tank truck to loading and transporting.
The LPG tank volume from 5~120 m3 for above ground, 5~100 m3 for underground.
The LPG tank trailer volume from 30~60 m3 with two axles or three axles.
The LPG tank truck with the volume from 5~35 m3.
If you're interested in our skid lpg gas refilling plant, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of CLW brand 25,000Liters skid lpg gas refilling station with scales manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of 25,000lITERS SKID LPG GAS REFILLING STATION as below.
Item | Unit | Specification | |||||||
Loading object | CLW25-12-12 | ||||||||
Material | Propane Gas | ||||||||
Designed loading Parameter | Option | Q345R, 16MnIII, Q370R | |||||||
Kg/m3 | 420~ 500 | ||||||||
Dimension | mm | 7594*2124*2714 | |||||||
Net Weight | Kg | 24960 | |||||||
Designed Pressure | Mpa | 1.77 | |||||||
Max Working Pressure | Mpa | <=1.6 | |||||||
Designed Temperature | C | -20~50 | |||||||
Volume | m3 | 25 | |||||||
Body thick | mm | 12 | |||||||
Cover thick | mm | 12 | |||||||
Man Hole | mm | 450 | |||||||
Top Safety Valve Port | mm | 80 | |||||||
Life Year | Year | 10 | |||||||
Input and output | |||||||||
Liquid input Port | mm | DN50 ( 2 Inch) | 2.5Mpa | ||||||
Liquid Output Port | mm | DN50 (2 Inch) | 2.5Mpa | ||||||
Bottom Air gas input Port | mm | DN50 (2 Inch) | 2.5Mpa | ||||||
Waste Liquid Output Port | mm | DN50 (3 Inch) | 2.5Mpa | ||||||
Top Gas Let Out Port | mm | DN50 (3 Inch) | 2.5Mpa | ||||||
Liquid Level Indicator Port | mm | DN20 | 2.5Mpa | ||||||
Essential Device for option | |||||||||
Safety Valve, Temperature Gague, Pressure Gauge | |||||||||
Option~ flange | |||||||||
Production Standard | |||||||||
China GB 150 Pressure Vessel Manufacturer Standard, Or ASME Standard | |||||||||
Designed Valid Year, at least 10 year |
