Truck chassis model: SC1031XND64A
Engine model:DK15C 82KW gasoline engine
Sweeping width: 2M
Inhalation particle size:φ120mm.
Water tanker volume: 0.7m³
Dust tanker volume: 1.8m³
Max working ability: 13000㎡/h-40000㎡/h
The functions of CLW brand road sweeper truck manufacture by Chengli Special Automobile Co., Ltd. as below.
1. Adopt the suction and sweep mixing method to collect garbage, wet dust removal, electro-hydraulic control, and hydraulic tipping and unloading operations to clean the road surface.
2. The auxiliary engine is used to drive the fan and hydraulic system to ensure that it can continue to work during driving and ensure the continuity of the cleaning process.
3. The structure layout of "four sweeping discs in the center + spray dust suppression device + central partition + rear suction nozzle" is adopted to prevent sand and gravel from splashing and dust during the cleaning process. This layout is convenient for the adjustment and maintenance of the cleaning device and the suction cup. The vehicle has good passability during field operations.
4. The transmission setting between the auxiliary engine and the fan is equipped with an automatic clutch, which can ensure the automatic separation of the auxiliary engine from the fan when the auxiliary engine starts and stops without load, reduces the impact on the auxiliary engine, and improves the working reliability and use of the auxiliary engine life.
5. The scanner has automatic avoidance protection function and automatic reset function when encountering obstacles. It automatically retracts when encountering obstacles and automatically returns to position when it crosses obstacles.
6. The speed of the sweeping disc can be adjusted according to various cleaning conditions, which can ensure a good cleaning effect under various pollution conditions
7. It adopts advanced and efficient dedicated fan and fully floating suction nozzle that can be leveled automatically with the road surface, which has good cleaning effect and long service life.
Parameters of dongfeng tuyi gasoline road sweeper truck head
Wheelbase: 2600mm, 1650 single row driver cab, liuji LJ4A15Q6 113hp gasoline engine,5 speed gearbox,175R14 tubeless tires*6, 1.5 front axle/2.5 rear axle, Standard power steering, front disc brake, central control door lock, electric doors and windows, cruise control, Bluetooth phone, LED daytime running lights, ABS, air conditioning, and reserved power take-off window.
If you're interested in our road sweeper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Truck chassis model: SC1031XND64A
Engine model:DK15C 82KW gasoline engine
Sweeping width: 2M
Inhalation particle size:φ120mm.
Water tanker volume: 0.7m³
Dust tanker volume: 1.8m³
Max working ability: 13000㎡/h-40000㎡/h
Standard configuration for the bodywork: with 4 sweeping disks, Yunnei 42KW auxiliary engine, Sanyo motor, Schneider control switch, Hypreis solenoid valve group, infinitely variable automatic clutch, maintenance-free centrifugal automatic fan, stainless steel dustbin, Shanghai Xinxishan Electronics Water pump, LED arrow indicator on the tail, manual pump emergency system, garbage lifting and self-unloading function, etc.
More pictures of Chang'an gasoline engine road sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of Chang’an road sweeper truck as below.
| Main technical parameters |
| Truck model |
CLW5030TSLS6 |
| Total mass(Kg) |
2840 |
Overall dimension(L*W*H)(mm) |
4810×1850×2150 |
| Rated mass(Kg) |
160 |
Curb mass(Kg) |
2550 |
| Driver cab seated person |
2 |
Axle nos. |
2 |
| Approach/departure angle(°) |
40/23 |
Front/rear suspension(mm) |
720/1390 |
| Axle load(Kg) |
1290/1550 |
Max speed(Km/h) |
100 |
| Chassis |
| Truck model |
SC1031XND64A |
manufacturer |
Chang’an |
| Wheelbase (mm) |
2700 |
| Tire specification |
175R14LT 8PR |
| Teel spring |
4/5 |
Front tread(mm) |
1372 |
| Fuel type |
gasoline |
Rear tread(mm) |
1300 |
| Emission standard |
Euro Ⅵ |
| Engine model |
Manufacturer |
displacement(ml) |
power(Kw) |
| DK15C |
Yu’an huaihai |
1498 |
82 |
