|Place of Origin:||China|
|Certification:||CCC, ISO 9001|
|Minimum Order Quantity:||1 unit|
|Packaging Details:||in bulk package, waxed|
|Delivery Time:||20 days|
|Payment Terms:||T/T, L/C|
|Color:||Different Color Upon Request, Free To Paint Company Logo||Price:||High Quality Factory Direct Sale Price|
|Truck Chassis:||Chinamade Dongfeng Tianjin 190hp LHD Diesel Truck Chassis|
Hot sale! Dongfeng TIANJIN 190HP Euro 3 diesel 10cbm asphalt spreading tanker truck for sale, new 8tons asphalt distributing vehicle for sale
Dongfeng Tianjin 4*2 LHD 10cbm bitumen distributing tanker truck, adopts dongfeng Tianjin luxurious one row and a half luxurious driver cab, 4500mm wheelbase, B190 33 Cummins 190hp diesel engine, 10,00R20 rail tires, 5t front axle/10t rear axle, 8 speed manual gearbox, power steering and air cut braking, 250mm double layers beam, etc.
The devices of dongfeng tianjin 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).
2, hydraulic system: Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve; radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L or Power take off after engine GPC4-50R.
3, control way: Intelligent touch screen computer control at the driver cab; control system: (Siemens, Germany), 36 sets intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil
5, gasoline generator unit: 6KW
6, spreading amount: 0.25-3.5L/㎡;
7, asphalt distributing width: 4.5m, 48 sets spraying nozzles for 6m spreading width is selective (10000RMB additional).
8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
If you're interested in our asphalt tanker distributing truck, please send email to email@example.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of dongfeng tianjin 8tons asphalt spreading tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
main technical parameters of dongfeng tianjin 8tons asphalt spreading tanker truck as below.
|Main technical parameters|
Dongfeng Tianjin asphalt spreading tanker truck for sale
|Total mass(Kg)||15800||Tanker volume(m3)||10|
|Rated mass(Kg)||6405||Overall dimension(L*W*H)(mm)||8590×2480×2840|
|Curb mass(Kg)||9200||Driver cab seated person||2,3|
|Approach/departure angle(°)||20/10||Front/rear suspension(mm)||1430/2660|
|Axle load(Kg)||5600/10200||Max speed(Km/h)||98|
|Truck chassis main parameters|
|Approach/departure angle(°)||20/18,20/13,20/19||Tire specification||10.00R20|
|Steel spring||8/10+8,||Front tread (mm)||1880,1900,1920,1815|
|Fuel type||Diesel||Rear tread(mm)||1800,1860,1820|
|Emission standard||Euro Ⅲ|
|Engine model||Manufacturer||displacement(ml)||Power (KW)|
|B190 33||DONGFENG CUMMINS||5900||140|
