Place of Origin: | China |
Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request, Free To Paint Company Logo | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Truck Chassis: | Chinamade Dongfeng LHD D9 180hp Diesel Euro 4 Truck Chassis |
Customzied Dongfeng D9 4*2 LHD 180hp Euro 4 diesel 10cbm asphalt spreading tanker truck for Philippines, bitumen distributing tanker vehicle for sale
Dongfeng D9 10cbm bitumen distributing tanker truck, adopts dongfeng D9 one row and a half luxurious driver cab, 4500mm wheelbase, ISD180-43 Cummins 180hp Euro Ⅳ diesel engine, 9,00R20 rail tires, 4.5t front axle/10t rear axle, 8 speed manual gearbox, etc.
The devices of dongfeng D9 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).
2, hydraulic system: Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve; radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L or Power take off after engine GPC4-50R.
3, control way: Intelligent touch screen computer control at the driver cab; control system: (Siemens, Germany), 36 sets intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil
5, gasoline generator unit: 6KW
6, spreading amount: 0.25-3.5L/㎡;
7, asphalt distributing width: 4.5m, 48 sets spraying nozzles for 6m spreading width is selective (10000RMB additional).
8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
If you're interested in our asphalt tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of dongfeng D9 180hp Euro 4 diesel asphalt tanker truck as below.
Main technical parameters of dongfeng D9 10cbm asphalt tanker spreading vehicle manufactured by Chengli Special Automobile Co., Ltd. is as below.
Main technical parameters | |||
Product name | CLW5180GLQ6 asphalt spreading vehicle for sale | ||
Total mass(Kg) | 18000 | Tanker volume(m3) | 10.0 |
Rated mass(Kg) | 8690,8625 | Overall dimension(L*W*H)(mm) | 8160×2500×3060 |
Curb mass(Kg) | 9180 | Driver cab seated person | 2,3 |
Approach/departure angle(°) | 19/15 | Front/rear suspension(mm) | 1260/2400 |
Axle no. | 2 | wheelbase(mm) | 4500 |
Axle load(Kg) | 6500/11500 | Max speed(Km/h) | 105 |
Chassis main technical parameters | |||
Chassis model | EQ1185LJ9CDE | Manufacturer | Dongfeng company |
Approach/departure angle(°) | 19/13,19/17 | Tire specification | 10.00R20 18PR, |
Steel spring | 8/10+7, | Front tread(mm) | 1933, |
Fuel type | Diesel | Rear tread(mm) | 1865 |
Emission standard | Euro Ⅲ | ||
Engine model | Manufacturer | Displacement (ml) | Power(Kw) |
ISD180-43 | Cummins | 4500 | 132 |
