Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Model Number: | CLW5097TZJ6 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request, Free To Paint Company Logo | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Truck Chassis: | Chinamade Dongfeng D9 LHD Diesel Truck Chassis |
Drilling rig truck is also called Water Well Drilling Rig truck, truck mounted drilling rig, vehicle-mounted drilling rig, truck vehicle mounted Water Well Drilling Rig, truck mounted water well drilling rig machine, etc.
Dongfeng D9 Drilling Rig vehicle adopts dongfeng duolika D9 truck chassis, yuchai 200hp Euro 5 diesel engine, 4500mm wheelbase, 10.00R20 rail tires*6+1, 6 speed gearbox, with power steering and air cut braking, original air conditioner, etc.
The main upper parts of the truck mounted drilling rig: Reduction Gearbox, Gyrator, winch, gearbox, mud/slurry pump, PTO, derrick, tower frame, water tap, etc.
The parameters of dongfeng D9 water well drilling rig mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Brand: Dongfeng
Model: CLW5097TZJ6
Drilling hole diameter: 200mm
Drilling hole depth: 100m
Drilling hole angle range: 90°
Electronic motor power: 147kv
Mass: 9200kgs
Customized: yes
Crushing Mode: Percussive-rotary drill rig
Construction site: Surface drilling Rig
Explorating drilling rig depth: Medium depth drilling hole
Usage: Hydrogeology water well drilling rig
Truck mounted drilling rig for Geological Survey, Geological and mineral exploration drilling rig, North Motor drill, Geological drilling rig.
SCOPE OF USE for the water well drilling rig mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Used for Construction of seismic blasting hole
Used for Shallow hole construction for general exploration of petroleum, natural gas and solid minerals
Used for Urban Construction, railway and hydropower departments carry out engineering geological survey and construction
Used for Shallow hydrogeological survey and water well drilling.
If you're interested in our truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of dongfeng D9 water rig drilling mounted on truck as below.
The technical specification of CLW brand well drilling rig mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Maximum drilling depth |
Drilling hole diameter:ψ200mm at 70m depth Drilling hole diameter:ψ150mm at 100m depth |
|
Drilling rod diameter |
mm | |
Rotator speed |
R/min | Inverse rotating/ 57 96 169 |
Reverse rotating / 38 | ||
Maximum feed/ Pull-up force |
KN | 30/50 |
Feed schedule |
mm | 450 |
Hoisting force of single rope |
KN | 13 |
Max working pressure of the mud/slurry pump |
Mpa | 2 |
Max displacement of the mud/slurry pump |
1/min | 450 |
Max pressure of the hydraulic system |
Mpa | 8 |
Overall dimension(L*W*H) |
mm | 9360*2530*3580 |
Curb mass |
kg | 9200 |
