Factory sale! new dongfeng 100m depth water well drilling rig mounted on truck, best price Customized cargo truck with water well drilling machine for sale,
The main advantage of truck with water well drilling rig machine as below.
1 Hydraulic pressure and strong lifting, saving manpower and reducing labor intensity.
2 The hoist is a planetary hoist, which is flexible in operation, safe and reliable.
A reverse gear mechanism is added to the gearbox, and a handle can be manipulated to enable the gyrator to have three positions of forward rotation, stop, and reverse rotation, which makes the active drill rod easy to unscrew, time-saving and labor-saving.
3 The mud pump has a strong self-priming ability, with adjustable 10-level flow.
4 The faucet is small in size, light in weight and reliable in sealing.
5 The active drill pipe has good rigidity and self-heavy weight. It can be pressurized by its own weight when drilling, and the drilling efficiency is high.
6 The lifting and lowering derrick is hydraulically operated, which is convenient, safe and reliable to operate.
7 The whole vehicle is equipped with four sets of hydraulic outriggers, which can adjust the extension length of any leg at will to adapt to different working places.
8 The automobile transfer case is an integral, military off-road type.
9The forward and reverse rotation of the drilling rig can be realized on the console, and the operation is convenient and flexible.
The parameters of dongfeng 100m depth water well drilling rig mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
● Brand: Dongfeng
● Model: CLW5097TZJ4
● Drilling hole diameter: 200mm
● Drilling hole depth: 100m
● Drilling hole angle range: 90°
● Electronic motor power: 147KW
● Mass: 9200kgs
● Customized: yes
● Crushing Mode: Percussive-rotary drill rig
● Construction site: Surface drilling Rig
● Explorating drilling rig depth: Medium depth drilling hole
● Usage: Hydrogeology water well drilling rig
● Truck mounted drilling rig for Geological Survey, Geological and mineral exploration drilling rig, North Motor drill, Geological drilling rig.
SCOPE OF USE for the water well drilling rig mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
● Used for Construction of seismic blasting hole
● Used for Shallow hole construction for general exploration of petroleum, natural gas and solid minerals
● Used for Urban Construction, railway and hydropower departments carry out engineering geological survey and construction
● Used for Shallow hydrogeological survey and water well drilling
If you're interested in our water well drilling rig truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of customized dongfeng water well drilling rig machine mounted on truck as below.
main technical parameters of water well drilling rig truck as below.
| MMaximum drilling depth |
Drilling diameter ψ200mm, hourly depth 70m
Drilling diameter ψ150mm, hourly depth 100m
|
| RRotating speed |
Forward rotation / 57 96 169 Reverse rotation / 38 R/min |
| MMaximum feed force/pull force |
30/50 KN |
| GGive progress |
450 mm |
| HHoisting single rope lifting force |
13 KN |
| MMaximum working pressure of mud pump |
2 MPA |
| MMaximum displacement of mud pump |
450l/min |
| MMaximum pressure of hydraulic system |
8 Mpa |
