Truck mounted crane is also called truck with crane, cargo truck with crane, flatbed truck with crane, lorry truck mounted crane, telescopic boom truck, telescopic truck mounted crane, crane truck, etc.
1. Optional crane truck brands: Dongfeng, SINOTRUK, HOWO, JAC, JMC, Foton, Forland, Hino, Iveco, YUEJIN, Isu zu, FAW, Shacman, Beiben, etc.
2. Driving type: 4x2, 4x4, 6x4, 6x6, 8x4 truck with crane, left hand drive or right hand drive.
3. Crane type: Straight / folding arm telescopic crane, 360-degree full rotation.
4. Optional crane capacity: 1 ton, 2 ton, 3.2 ton, 4 ton, 5 ton, 6.3 ton, 8 ton, 10 ton, 12 ton, 14 ton, 16 ton, 25 ton.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
more pictures of Donggfeng 4*2 RHD 6.3T mobile cargo truck with crane manufactured by Chengli Special Automobile Co., Ltd. is as below.
Main technical parameters of dongfeng 4*2 RHD 190hp 6.1m length truck with crane as below.
|
Item
|
Parameter
|
|
Vehicle name
|
Dongfeng 153 truck with crane
|
|
Chassis model
|
EQ1120GLJ
|
|
Load capacity
|
10000-12000 kg
|
|
Curb weight
|
7945 kg
|
|
Overall dimensions
|
9000×2490×3550 mm
|
|
Body dimensions
|
6100×2300×600 mm
|
|
Wheel base
|
5100 mm
|
|
Fuel type
|
Diesel
|
|
Engine model
|
B190-33
|
|
Engine horse power
|
190 hp
|
|
Displacement
|
5900 ml
|
|
Emission standard
|
Euro 3
|
|
Tire specification
|
10.00R20
|
|
Number of tires
|
6+1 SPARE
|
|
Traction system
|
4×2
|
|
Transmission
|
6-speed with over drive
|
|
Max speed
|
90 km/h
|
|
Crane Type
|
Optional 5-6T straight/folding boom type telescopic crane
|
|
Equipment
|
Hydraulic valve is universal in the world on the safe side; three point floating type to protect crossbeam of the truck; all
hydraulic pressure and 360°turning;new H-shape type; high precise drawn tube;24°tie-in.
|
|
Production cycle
|
15-20 working days
|
|
Warranty
|
12 month, from the date of supply
|
|
Price
|
EXW/FOB/CFR/CIF/DAF/DDU
|
|
Payment terms
|
30-50% as the deposit, the rest payment must be paid when the production finished in our factory before delivery. All by T/T.
|
