HOT SALE! customized Dongfeng 4*2 LHD 5T-7T dump tipper truck with hydraulic cover, Factory sale good price domestic wastes collecting tipper truck for sale,
Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of dump truck in China since 2004s. And we can offer dongfeng dump truck, HOWO dump truck, ISUZU tipper truck, FAW dump tipper, North Benz dump truck, tipper trailer, etc. 4*2 dump truck, 4*4 dump truck, 6*4 tipper truck, 8*4 dump truck, etc. More information, please feel free to contact with Ms. Anita Deng.
More pictures of Dongfeng 5T-7T dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! Best price dongfeng 5t-7T dump tipper truck
Factory sale good price dongfeng 5T-7tons dump tipper truck for sale
10 units of dump tipper trucks for overseas clients.
HOT SALE!dump tipper truck with hydraulic cover for sale
If you're interested in our dump tipper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
The dump garbage truck is also called garbage dump truck, garbage collection truck,etc. It is mainly used to transport garbage to the garbage settlement station. The garbage tipper is with box and the rear door and top of the box cover can be opened by hydraulic.
main technical parameters of dongfeng 5T-7T dump tipper truck as below.
| General |
Truck Name |
DONGFENG LHD Dump truck |
| Drive Type |
4*2 |
| Total mass(kg) |
9400kgs |
| Loading capacity (kg) |
5,400KGS |
| Curb Weight (kg) |
3805 |
| Overall Dimensions L*W*H(mm) |
6995×2330×2550(mm) |
| Engine |
Engine Model |
YC4FA120-33 |
| Engine Brand |
Yuchai |
| Fuel Type |
Diesel |
| Power |
88kw/120HP |
| Emission Standard |
Euro III |
| Displacement(ml) |
2982 |
| Engine Type |
4 cylinder Vertical, in-line, water-cooled, |
| Chassis |
Chassis Brand |
Dongfeng |
| Front/Rear Axle Load(KG) |
3460/5940 |
| Tire No. |
6 |
| Tire Specification |
7.50R16 |
| Wheelbase (mm) |
3800 |
| Axle No. |
2 |
| Gear Box |
6 speed forward with 1 reverse, manual |
| Steering Wheel |
Left Hand Drive with power-assisted |
| Front/rear tread(mm) |
1831/1640 |
| Steel spring |
8/10+7 |
| Max speed(km/h) |
95 |
| Driver cab |
Dongfeng duolika 4*2 LHD single row driver cab with air conditioner |
| Tipping system |
Box inner dimension(mm) |
4300/4200*2100*500/800 |
| Box material |
Carbon steel, side sheet: 3mm thickness, bottom 4mm thickness |
| Hydraulic cylinder position |
Double cylinders at the center of the truck bottom |
| Discharge type |
Rear tipping |
| remark |
Clients choose to install environmental protection hydraulically cover |
