Cross-field dump truck for sale, mine-use dump tipper truck for sale 6*6 6 wheels drive
Customized dongfeng 153 6 wheels drive off-road dump truck for sale,
6*6 dump truck 6*6 6 wheels drive mineral speicial vehicle is modifided by dongfeng EQ2102g military carrier, the car is not only inherited the excellent off-road performance of the original 2102 military vehicle, but also changed the container to selfunloading It is suitable for loading and unloading of goods, suitable for logistics transportation, industrial and mining transportation, etc.
more pictures of Dongfeng 6*6 all 6 wheels drive off road dump tipper transportor as below.
Main technical parameters of dongfeng brand 6*6 eels drive off road mine-use dump tipper truck is as below
Basic technical condition | |
Model | Dongfeng 6*6 6 wheels drive off road dump truck for sale |
Engine | Dongfeng Dummins B190 33 |
Gearbox | A135 type, gear mechanical, five forward files, one reversing |
Transfer case | Machinery, two gears |
Drive bridge | Bridge shell type: with a half-axle sleeve stamping welding monolithic bridge shell, front bridge isometric universal joint type: three-pin |
Cab | Flat head all metal welding closed structure, with a torsional flip mechanism, the front of the seat, the intermediate seat and the assistant seat at the front of the cab. |
Tyres | 12.5R20(6+1)child off-road type |
Electrical appliance | 24V circuit system |
BASIC PARAMETERS | ||
Size parameters | Overall dimension(L*W*H)(mm) | 7760*2470*2740 |
Cargo box dimension(L*W*H)(mm) | 4800*2294*900 | |
Wheelbase | 3500+1200 | |
Approach/departure angle(°) | 35/34 | |
Quality parameters | Follow weight(kg) | 6725 |
Loading mass(kgs) | 3500 | |
Total mass | 10435 | |
Performance parameters | Max power (KW) | 140 |
Displacement(ml) | 5900 | |
Max torque (n.m) | 640 | |
Max speed(km/h) | 85 | |
Max grade-ability(%) | 60 | |
Mini ground clearance(mm) | 320 | |
Mini turning radius(m) | ≯8.3 | |
100KM fuel consumption(L) | 30 | |
Tanker capacity | 160+60 | |
