    Detailed Product Description
    Color: Different Color Upon Request, Free To Paint Company Logo Price: High Quality Factory Direct Sale Price
    Truck Chassis: Chinamade FAW LHD Diesel Truck Chassis Working Height: 13.5m Working Height

    good price FAW 4*2 LHD 13.5M working height truck mounted aerial working platform, jiefang hydraulic bucket vehicle



    FAW brand 4*2 LHD 13.5M working height truck mounted aerial working platform, adopts FAW VR truck chassis with power steering, and original air conditioner, 2800mm wheelbase, 6.50R16 rail tires, 5 speed manual gearbox, Q23-95E60 95hp Euro Ⅵdiesel engine, etc.



    FAW brand 4*2 LHD 13.5m working height folded truck mounted aerial working platform truck , adopts a folding crank arm structure, the operating arm is three-section folding, the working bucket and the turntable have double working positions, up and down operation, electro-hydraulic control, 360-degree rotation, four hydraulic outriggers, inside the working bucket It can control the start and stop of the engine, the boom has a hoisting hook system, the hook lifting weight is ≤900kg, the manned working bucket is 200kg, the steel tool box and the pattern anti-skid platform, and the stainless steel fence.

    The chassis hydraulic outrigger balance system is equipped with a two-way hydraulic lock as standard, the working arm cylinder is equipped with a two-way balance valve as standard, and the working arm balance structure is an external balance lever.

    The main components of Chengli aerial vehicle hydraulic cylinders, hydraulic tubing, hydraulic locks, balance valves, gear pumps, power take-offs, multi-way valves, etc., all adopt well-known domestic brands. The hydraulic system of the vehicle has stable reversing and flexible and convenient operation; The working arms are interlocked, safe and reliable, to prevent misoperation; H-shaped outriggers have a large span and good stability. The outriggers can be independently retractable and linked. The rear outriggers are equipped with outriggers and flashing lights for operation. When the outrigger is profiled, it sends out a light alarm signal.



    If you're interested in our truck mounted aerial working platform truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995



    More pictures of FAW brand 4*2 LHD diesel 13.5m hydraulic bucket truck manufactured by Chengli Special Automobile Co., Ltd. is as below.

    good price FAW 4*2 LHD 13.5M working height truck mounted aerial working platform, jiefang hydraulic bucket vehicle

    HOT SALE! FAW 13.5M truck mounted aerial working platform

    good price FAW 4*2 LHD 13.5M working height truck mounted aerial working platform, jiefang hydraulic bucket vehicle

    good price FAW 4*2 LHD 13.5M working height truck mounted aerial working platform, jiefang hydraulic bucket vehicle

    main technical parameters of FAW brand 4*2 LHD diesel 13.5m hydraulic bucket truck is as below.

    Item Name Model/type
    1 Product brand CLW-aerial working platform truck for sale
    2 Product name CLW5040JGKC6
    3 Chassis model CA1041P40K50L1BE6A84
    4 Max working height 13.5m
    5 Main technical parameters for working

    The distance between ground and working platform≥11.8m

    Max working range of the working platform≥6m

    Working range at the working platform max working≥2.5m

    Working height at the working platform max working range≥7.5m

    Max loading capacity of the working bucket: 200kgs

    Outriggers

    type:H type outriggers

    Nos.:4

    Operating way:Independently adjustable and can also be linked

    Horizontal span:2720mm

    Longitudinal span:2890mm

    Hook

    Max lifting mass ≤1000kg,Safety value: 800kg.

    Max lifting height: 5.6m

    Main operation

    Operation position: turntable, double working position operation of hanging bar

    Operation mode: Manual hydraulic or electronic control operation

    6 Hoarding and platform board Steel toolbox and hoarding, Pattern non-slip walking board, Stainless steel railing
    7 Boom structure 3 sections folded crane boom
    8 Slewing device Two-way 360° continuous rotation
    9 Engine model Q23-95E60
    10 Overall dimension(L*W*H) 5990×1980×2950
    11 Total mass 4495 kg
    12 Curb mass 4365 kg
    13 wheelbase 2800mm



    The technical advantages of CLW brand truck mounted aerial working platform manufactured by Chengli Special Automobile Co., Ltd. is as below.

    1. The working bucket adopts mechanical self-balancing design, and its function is that the working bucket is always in a balanced state when working.

    2. The rear outriggers of the vehicle are equipped with warning outline lights to improve the safety of warnings during vehicle operation.

    3. The upper and lower operating systems can complete various operations on the working bucket and on the turntable.

    4. The working bucket is equipped with night operation lights to make night operation safer.

    5. The outriggers are individually adjustable. Each outrigger can be adjusted separately according to the working ground environment. Even if the ground is uneven, the whole vehicle can be adjusted to a stable state.

    6. The outrigger adopts front and rear H-shaped structure, which has larger bearing surface and higher stability.

    7. The hydraulic system is equipped with a hydraulic locking system, whose function is to lock the cylinder in place after reaching the required position to prevent accidents.
