CLW Brand garbage compactor trucks are also called rear loader garbage truck, wastes collecting vehicles, etc. This kind of garbage truck is a kind of special purpose vehicle, mainly used for collecting, transporting and discharging bagged wastes, barreled wastes, bulk household wastes in towns and cities, etc.The wastes is pressured and pushed into the wastes van by the truck mounted wastes propeller (also called negative pressure mechanism), so that making the wastes distributing into the tank evenly and higher density and till full.The collecting and transporting way of the garbage compactor truck adopts widely all over the world. The function of the entire special device adopts the truck engine as power, realizing by hydraulic mechanism manual or electronic control.The wastes van and the loader, which is also called wastes tan and sewer tank, adopting high quality carbon steel with full-sealed welding structure, with the advantages of high strength, light weight, non second pollution, etc. More information, please contact with Ms. Anita. The hot sale line is 0086 13329899995.
We produce the 5m3 garbage compactor truck body to fit the customer's chassis. The product is customized! The design and the painting are according to customer's requirement.
The 5m3 garbage compactor truck body is used to collect the urban garbage then transfer them to the garbage station. Hang two 240L plastic trash bins on the flip rack, then operate the hydraulic system to pour the garbage in the bin into the hopper, then the scraper plate in the hopper squeeze the garbage and push them into the chamber box. All the operation of loading and unloading are controlled by hydraulic system, No manual operation required!
main technical parameters of ISUZU garbage compactor truck is as below.
|
Product Name
|
5m3 garbage compactor
|
|
Material
|
4mm carbon steel
|
|
Capacity
|
5m3
|
|
Dimension
|
5120x1920x2100mm
|
|
Weight:
|
3100kgs
|
|
Hopper Volume
|
0.8m3
|
|
Sewage Tank Volume
|
120 Liters
|
|
Hydraulic Oil Tank Volume
|
90Liters
|
|
Hydraulic System Pressure
|
16MPa/Bar
|
|
Electric Power
|
24V
|
|
Operation System
|
Both Manual and Electric
|
|
Painting
|
as per customer's requirement
|
