CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale

CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale

    • CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale
    • CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale
    • CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale
    • CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale
    • CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale
    • CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale
  • CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale

    Product Details:

    Place of Origin: China
    Brand Name: CLW brand
    Certification: ASME standard, GB 150

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package, waxed
    Delivery Time: 35 days
    Payment Terms: T/T
    Supply Ability: 20 units/month
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request Material: High Quality Q345R Material For Lpg Gas Pressure Vessels
    Price: Factory Direct Sale Price With High Quality

    CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale



    Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years’development, Chengli Special Automobile Co., Ltd. can supply surface lpg gas storage tank(5m3-200m3), underground lpg gas storage tank(10m3-80m3), lpg gas trailer(40,5m3-59.6m3), lpg gas truck(5m3-35.5m3), skid lpg gas plant(5-120m3), etc.And in 2016s, we have achieved the US ASME certificate for lpg gas pressure vessels, meaning we can design and mnufacture ASME standard lpg gas pressure vessels in our company and exporting, too.



    If you're interested in our lpg gas pressure vessels, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995





    The specification sheet of 5M3 pressure vessel product data sheet, hot sale 5,000L bulk lpg gas storage tank with factory price

    Equipment catalogue

    Stationary pressure vessel

    Varieties of pressure vessel

    Storage

    Product name

    LPG (propane) storage tank

    Product no.

    G150208

    Equipment no.

    /

    Category of pressure vessel

    Ⅲ class

    Product standard

    GB150 NB/T47042

    Designed working life

    15

    Main  data

    Volume

    5m3

    Internal diameter



    1600

    Tank length

    3070*1620*2210mm



    Material

    Body

    Q345R

    Thickness

    Body

    10mm

    Body weight

    2030kg



    Head

    Q345R

    Head

    10mm

    Inside components weight

    /kg



    Lining

    /

    Lining

    /mm

    Filling weight

    1995kgs



    Interlining

    /

    Interlining

    /mm



    Designed pressure

    Shell side

    1.77Mpa

    Designed pressure

    Shell side

    50 ℃

    Max working pressure

    Shell side

    /

    Tube side

    /Mpa

    Tube side

    /℃

    Tube side

    /

    Interlining side

    /Mpa

    Interlining side

    /℃

    Interlining side

    /

    Medium of shell side

    Liquid petroleum gas(propane)

    Medium of tube side



    /

    Medium of interlining side

    /

    Form of structure

    Main structure form

    Ellipse head, round body

    Installation

    Fixed horizontal installation

    Bearing type

    Saddle support

    Heat preservation heat insulation way

    -

    Testing

    Method of non-destructive testing

    RT PT

    Non-destructive testing rate

    100%

    Pressure  test type

    Hydrostatic test

    Puncture test pressure

    2.22MPa

    Heat treatment method

    Stress relieving heat treatment

    Heat-treatment temperature

    620±15℃



    Safety accessories

    Name



    Type

    Size

    Quantity

    Self-contained

    Magnetic flap liquid level

    UZFAI-2.5RF-2940-0.50

    DN25

    1

    HG21584

    Safety valve

    A42F-25

    DN100

    1

    GB12243, Pz=1.69MPa, K=0.65

    Pressure gage

    Y-150

    M20×1.5

    1

    0-4MPa, 1.6 grade

    Thermometer

    WTQ-280

    M33×2

    1

    -40℃-60℃, 1.5 grade

    Manufacture and supervisory situation

    Supervisory

    Hubei Institute of Special Equipment Inspection And Test



    Organization code

    42000423-5

    Organization Verification Certificate N0.

    TS711-215-2019

    More pictures of hot sale 5,000L surface lpg gas storage tank as below.

    CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale

    best price 5,000L surface lpg gas storage tank for sale

    CLW Brand mini 5,000L surface lpg gas storage tank for sale, ASME standard 5M3 bulk lpg gas storage tank for sale

    hot sale mini ASME standard 5,000L surface lpg gas storage tank



    More information, please feel free to contact with Ms. Anita Deng.

    Whatsapp/wechat: +86 13329899995

    Skype: truck0011

    QQ: 504873236
