Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of milk truck, milk tank, milk tank trailer, tank truck for milk, stainless steel milk tank, food grade tanker, farm pickup tank truck, liquid food tank, milk trailer, etc. With many years’supplying, Chengli Special Automobile Co., Ltd. could supply 5000L-25000L milk tank truck, 30000L-50000L milk tank trailer, dongfeng milk tank truck for sale, FAW food grade milk truck for sale, ISUZU milk truck for sale, Forland milk truck, etc.More information, please feel free to contact with Ms. Anita Deng.
Fresh milk transport vehicle modification configuration: the tank structure is divided into three layers: insulation layer, insulation layer and tank body.
One. The body of the frame can be made of food grade 304 material stainless steel plate, and the tank body can be made into 2-3 cabins. The tank body requires smooth and no acute angle. A cip (cleaning device) tank is provided in each milk tank with a washer.
Second, the middle of the tank is an insulation layer, which has a heat preservation effect to prevent deterioration of fresh milk. The temperature change does not exceed 1 degree for 24 hours at a temperature difference of 30 degrees. The insulation material is insulated with 80 (mm) thick polyurethane foam material.
Third, the outer layer of the tank (protective layer of the insulation layer) is made of 2mm thick 304L stainless steel. The outer skin and trunk of stainless steel are beautiful in appearance, the whole body is beautiful in appearance, scientific in structure, light in weight and good in strength.
4. Each single warehouse has a separate discharge port (self-flow port) and a feed port (can port).
5. Optional chiller, rock wool insulation, exhaust gas circulation heating, and stainless steel pump to make the vehicle have a suction function.
If you're interested in our milk truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
The main technical parameters of dongfeng 5,000L Euro 4 milk tank truck as below.
|
Truck chassis:
Dongfeng xiaoduolika truck chassis, new model 1730 single row truck body, chaochai 95hp Euro 4 diesel engine, 5 speed transmission, 7.00R16 tryes*6+1, 1.8ton front axle/3.5tons rear axle, 188mm beam, power steering, air cut braking, etc.
Milk tank device: milk tan adopts 304-2B foodgrade stainless steel, 8mm thickness PU foam, one compartment with one self-discharging outlet and PIC cleaning device.
The insulation function: the temperature will be changed one degree within 24 hours
|
|
Dongfeng 5,000L fresh milk tank truck for sale
|
|
Product name
|
Dongfeng 5,000L fresh milk tank truck for sale
|
Overall dimension
|
5995X2000X2400(mm)
|
|
Truck chassis model
|
DFA1070SJ35D6
|
Tank dimension
|
XX
|
|
Total mass
|
7300(Kg)
|
Rated mass
|
4220,4155(Kg)
|
|
Curb mass
|
2950(Kg)
|
Max speed
|
95(km/h)
|
|
Truck chassis main parameters
|
|
Truck chassis
|
DFA1070SJ35D6
|
Fuel type
|
Diesel
|
|
Axle nos.
|
2
|
Oil cunsuption
|
15.4L/100km
|
|
Wheelbase
|
3300
|
Tyre nos.
|
6
|
|
Seated person
|
2,3
|
Tyre specification
|
7.00-16 14PR,7.00R16 14PR
|
|
Emission standard
|
Euro Ⅳ
|
|
Engine main parameters
|
|
Engine model
|
Manufacturer
|
Displacement (ml):
|
Power (kw):
|
|
CY4102-CE4F
|
Chaochai engine
|
3856
|
73
|
There are three layers of the milk semi-trailer, the inner tanker is manufactured by 4mm thick 304/2B food grade stainless steel; the middle is 80mm PU foam insulation layer, and 60mm PU foam of the manhole part, the temperature will be changed one degree within 24 hours; the exterior of the tanker is 1.2mm thick 304 stainless steel mirror panel.
The inner tanker has cleaning device, cleaning rod(cleaning ball), cleaning pipe(with the diameter of 38mm), turntable cleaning sprayer, etc. Automatically cleaning when with water source.
More pictures of hot sale 5,000L milk tank truck as below.
