Place of Origin: | China |
Brand Name: | Shacman Brand |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20uits/month |
Color: | Different Color Upon Request | Price: | Different Color Upon Request |
---|---|---|---|
Truck Chassis: | China Famous Leading Shacman Brand 8*4 Truck Chassis |
Factory direct sale Shacman F3000 LHD 6*4 heavy duty 30tons Tipper, best price Shacman Brand F3000 30tons-40tons dump tipper for sale
Dump truck is also called as tipper truck or engineering truck, which consist of chassis, hydraulic lifting mechanism, cargo. It can be divided into light duty series, medium duty series, heavy duty series. And it’s widely used in engineering, road construction, sanitation, mines, lime kilns, stones factory, cement stash factory, phosphate fertilizer plant, etc. it can save manpower and reduce labor intensity.
Equipment: the truck is adopted with optimized design hydraulic system and lifting mechanism. It’s lifting is smooth and powerful. The tipper dumping mechanism is using push to enlarge the structure by the former, former top cylinder and middle double cylinder.
1. dump truck adopt with the original maturity chassis to refit.
2. the cargo is made of high quality carbon steel. The cargo thickness can be 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, etc. it’s made in accordance with international standards of manufacturing.
3. the shape can be square bucket, U-shape bucket.
1. Chinese famous heavy duty chassis brand in China---Shacman
2. Low oil consumption with strong horse power 366hp
3. Large load capacity 30-40ton
4. LHD or RHD are optional
If you're interested in our dump tipper truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Main parameters of hot sale Shacman Brand F3000 dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. as below
[ Main Technical Parameters ] |
|||||
Product Name |
Dump Truck |
Gross Vehicle Weight(kg) |
25000 |
||
Rated Payload(kg) |
12 470 |
Curb Weight(kg) |
1 2400 |
||
Overall Dimension(mm) |
9699 ×2 490 ×3 45 0 |
Box Dimension(mm) |
70 00 × 2300 × 88 0 |
||
Cab Allowed Persons |
2 |
Mass Utilization Coefficient |
1.0 0 |
||
App/Dep Angle(°) |
28 / 30 |
F/R Suspension(mm) |
1 525 / 290 0 |
||
Axle No. |
3 |
Wheelbase(mm) |
4575 +1 40 0 |
||
Axle Load(Kg) |
7000/18000(parallel installed) |
Max Speed(Km/h) |
90 |
||
[ Chassis Technical Parameters ] |
|||||
Chassis Model |
SX3255DR384 |
Chassis Brand |
SHACMAN |
||
Overall Dimension(mm) |
8750 ×2 490 × 3720 |
Tyre No. |
10 |
||
App/Dep Angle(°) |
28 / 30 |
Tyre Specification |
1 1. 00-20 or 11.00R20 |
||
Spring Leaf No. |
10 / 12 |
Front Track(mm) |
20 18 |
||
Fuel Type |
Diesel |
Rear Track(mm) |
18 60 /18 60 |
||
Clutch |
¢430mm diaphragm spring |
Steering |
ZF Technology |
||
Gear box |
Fast 10JSD140 |
Front/Rear Axle |
MAN 9000kg/MAN 16000kg |
||
Oil Tank |
300L Aluminum |
Air Condition |
Equipped |
||
Emission Standard |
Euro II |
Brake |
Air Brake |
||
Engine Model |
WD 615.69 |
Engine Brand |
Sinotruk |
||
Engine Power(k w ) |
336HP |
Displacement(ml) |
9726 |
||
[ Superstructure Technical Parameters ] |
|||||
Material of Box |
Carbon Steel |
Paint |
Metallic Paint |
||
Thickness of side plate |
6 mm |
Thickness of bottom plate |
8 mm |
||
Lifting Mode |
Front lifting |
Loading Mode |
Rear tipper |
More pictures of hot sale Shacman brand dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. as below
Shacman Brand dump tipper truck for sale
Best price Shacman brand 40tons tipper truck for sale
