Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck

Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck

    • Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck
    • Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck
    • Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck
    • Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck
    • Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck
  • Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck

    Product Details:

    Place of Origin: China
    Brand Name: FOTON
    Certification: CCC, ISO 9001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package. waxed
    Delivery Time: 20 days
    Payment Terms: T/T, L/C
    Supply Ability: 20units/month
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request Price: High Quality Factory Direct Sale Price
    Truck Chassis: FOTON Brand 4*2 LHD Truck Chassis Discharging Way: Hydraulic System Discharging Or Electronic System Discharging





    Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented animal feed delivery truck



    bulk feed tank is installed on the truck chassis; there is one mouth for loading at the tank top. And the helical delivering discharging pipe (also called discharging auger) on the tank top can rotate and upraise freely with the upraise angle of 60 degree. When transporting, the helical pipe lay on the tank top; when discharging, upraise. Connected the discharging feed outlet with the top inlet of feed storage tank controlled by the operation device at the driver cab or the tank rear part.



    With the development of the livestock husbandry, the bulk feeds trucks become more and more important. Some small feedstuff factory actually don’t need large tonnage feed pellet truck. For this, Chengli Special Automobile Co., Ltd. designed and produced new small bulk feed transportation trucks for the small feeds factories, that is dongfeng 4ton bulk feed pellet truck-dongfeng furuika bulk grain carrier. This model of powder feed transportation tank truck is with the volume of 8cbm, adopts dongfeng furuika original chassis, high quality and competitive price, easy operation and maintenance, etc.



    If you're interested in our poultry feed truck, please send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995



    Main parameters of hot sale forland LHD 12tons livestock and poultry feed truck as below

    Foton brand LHD 4*2 livestock and poultry feed truck for sale

    Main parameters

    Product name Foton brand chick feed transported truck for sale Overall dimension(mm): 8450x2336x3600
    Truck chassis model BJ1129VFPEG-FA Cargo body dimension(mm):
    Total mass(kg) 11375 Approach/departure angle(° ) 23°/10°
    Rated mass(kg) 4990 Front/rear suspension(mm): 1195/2555
    Curb mass(kg) 6190 Max speed(km/h): 99
    Axle load(kgs) 3980/7395




    Truck chassis main parameters
    Truck chassis mode; BJ1129VFPEG-FA Fuel type Diesel
    Axle load 2 Front tread(mm): 1710,1830
    Wheelbase(mm): 4700 Rear tread(mm): 1680,1800
    Tire nos. 6 Tire specification 8.25-20 16PR,8.25R20 16PR,9.00-20 14PR,9.00R20 14PR




    Engine parameters
    Engine model Manufacturer Displacement(ml) Power (kw)
    ISF3.8s4168 ISF3.8s4R168 Cummins 3760 3760 125 125
    Emission standard Euro 4 Fuel type Diesel



    Feed tank volume 20cbm Discharging speed 500-600 kg/min
    Full discharging time 18mins Discharging max elevation 70 degree
    Horizontal delivering range 6.5m Rotation angle of discharging 180 degree
    Vertical delivering range 8.3m Compartments 3 compartments loading 3 different kinds of feeds
    Discharging way Hydraulic auger system discharging, 380Volts electronis auger discharging is selective.


    Remark: 1, for the density of the feeds is various, so the loading tonnage is also various. The tank volume is 20cbm.

    when the feeds density is 0.55ton/cbm, 0.6ton/cbm, 0.7ton/cbm, the loading mass is 11ton, 12ton, 14ton.

    2, the bulk feeds truck adopts the special bulk feeds truck chassis, widely for long distance transportation, large size feedstuff factories, etc.



    More pictures of hot sale FOTON brand chick feed pellet truck as below.

    Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck

    animal feed delivery truck for sale

    Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck

    FOTON brand livestock and poultry feed delivery truck for sale





    Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck

    hydraulic animal feed truck for sale



    More information, please feel free to contact with Ms. Anita.

    Whatsapp/Wechat: +86 13329899995

    Skype: truck0011

    QQ: 504873236
