best price and high quality CLW brand 30tons bulk feed tank trailer for sale, factory direct sale 30tons farm-oriented livestock and poultry animal feed trailer
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of bulk feed truck and animal feed trailer in China. With many year's development, ChengLI Special Automobile Co., Ltd. could offer 8m3 to 40m3 bulk feed delivery trucks and 40m3-50m3 animal feed tank trailer, etc. The animal feed tanks manufactured by Chengli Special Automobile Co., Ltd. are discharging by 380V three-phrase electronic power or hydraulic system. More information, please feel free to contact with Ms. Anita. Please feel free to send email to firstname.lastname@example.org or talk to Anita directly by whatsapp/wechat: +86 13329899995.
Triple axles 46cbm bulk feed tank semitrailer, adopts 3 sets of FUWA 13ton bridges, 11.00-20 tyre, 28ton outriggers, 90# /50# traction pin, etc.
The bulk feed tank volume of 46cbm, with the loading capacity of 25tons, adopts high quality 5mm carbon steel, transferring feeds by electronic auger, working with putting on 380volts electronic power. The electronic motor drives the Mechanical auger screw type to discharge with high discharging speed of 0.55ton/min. The Barrel type auger at the tank top is driven by the hydraulic motor, and the electronic bottom control lifting up and down, rotation left and right, with the horizon range of 7.2m and vertical range of 8.2m. So little Residual rate, less than 0.1. And the feed pellet semitrailer can be continuous working, highly improving the working productiveness.
There are 5 compartments of the feed trailer, 5 separate compartments with 5 different kinds of feeds. Every unit is with simple structure, easy and flexible operation, easy to maintenance, etc.
The main parameters of hot sale CLW brand 25tons farm-oriented feed trailer as below
|CLW 55m3 bulk feed tank semitrailer for sale|
|Total mass(kg)||38100||Tank volume||55|
|Loading capacity||25,000kgs||Curb mass(kg)||15725|
|Approach/departure angle||-/14||Bearing quality of semitrailer saddle (kg)||15000|
|Overall dimension(L*W*H)(mm)||11000*2500*2550||Cargo body dimension(mm)||XX|
|Axle nos.||3||Axle load(kg)||-/23100(triple axles)|
|Tyre||11.00-20 12PR||Tyre nos.||12+1|
|Front/rear tread(mm)||-;1840/1840/1840||Steel spring||-/8/8/8,-/10/10/10|
|Feed tank main parameters|
|Feed tank volume||55m3||Loading capacity||30tons (different for different density)|
|Material||High quality carbon steel||Thickness||5mm|
|Feed density||0.55tons/m3||Compartments||5 compartments for 5 different feed pellet|
|Discharging way||Electronic auger system discharging by 380 volts electronic power||Discharging speed||0.55tons/min|
|Rotation way||360°full rotation||Residual rate||＜0.1|
|Vertical distance||8.2m||Horizon distance||7.2m|
|Axles nos.||3||Axle specification||FUWA brand axles|
|Tractor pin||90# or 50# tractor pin||Outriggers||28tons JOST brand outrigger|
More pictures of hot sale CLW brand 30tons animal feed trailer as below
30tons CLW Brand animal feed tank trailer for sale
best price and high quality farm-oriented animal feed transported semitrailer for sale
30tons CLW brand animal feed pellet tank trailer for sale
