Place of Origin: | China |
Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 35days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Differnet Color Upon Request | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Material: | High Quality Carbon Steel Material |
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years' development, we could offer lpg gas tank, lpg gas trailer, lpg gas delivery truck, lpg gas dispensing truck, skid lpg gas filling station, etc. More information, please feel free to contact with Ms. Anita.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years’development, Chengli Special Automobile Co., Ltd. can supply surface lpg gas storage tank(5m3-200m3), underground lpg gas storage tank(10m3-80m3), lpg gas trailer(40,5m3-59.6m3), lpg gas truck(5m3-35.5m3), skid lpg gas plant(5-120m3), etc.And in 2016s, we have achieved the US ASME certificate for lpg gas pressure vessels, meaning we can design and mnufacture ASME standard lpg gas pressure vessels in our company and exporting, too.
More pictures of hot sale anhydrous ammonia storage tank manufactured by Chengli Special Automobile Co., Ltd. as below
CLW Brand surface lpg gas storage tank for anhydrous ammonia for sale
If you're interested in our lpg gas storage tank, please send email to truck0011@163.com or talk to Anita directly by Whatsapp/wechat/Mob.: +86 13329899995.
main technical parameters of hot sale anhydrous ammonia storage tank manufactured by Chengli Special Automobile Co., Ltd. as below
Item | Unit | Main parameters |
Product name | LPG gas storage tank for sale (20,000L) | |
Loading medium | LPG gas (Anhydrous ammonia) | |
Overall dimension(L*W*H) | mm | 6162*2132*2710 |
Tank dimension(inner diameter*thickness*length) | mm | DN2100*16*6162 |
Tank volume | m3 | 20 |
Tank thickness | mm | 16 |
End heads thickness | mm | 16 |
Curb mass | kg | 6162 |
Loading capacity | Kg | 9880 |
Designed pressure | Mpa | 2.16 |
Working pressure | Mpa | ≤1.6 |
Working temperature | ℃ | ≤50 |
Hydraulic test pressure | Mpa | 2.22 |
Air tight test pressure | Mpa | 1.77 |
Medium density | Kg/m3 | 580 |
Corrosion allowance | mm | 1.5 |
Tank and main Material pressure components | Q345R,16Mnlll | |
Standard | <<GB150steel pressure vessel>>,<<Supervision Regulation on Safety Technology for Pressure Vessel>> | |
Chosen assembly | Safety valve, magic level gauge, pressure gauge, temperature gauge, cut-off valve, etc. |
Liquid ammonia storage tank is widely used for chemical plants to store liquid ammonia. And the manufacturing process of lpg gas tank for ammonia is line with China National Pressure Vessel standard.
