Place of Origin: | China |
Brand Name: | DONGFENG |
Certification: | CCC,ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package,waxed |
Delivery Time: | 20days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request | Price: | High Quality And Competitive Price |
---|---|---|---|
Truck Chassis: | Dongfeng 4*2 LHD Diesel Truck Chassis |
High qulaity and best price Dongfeng 4*2 LHD dump tipper for stones and coals for sale, China good price 8tons-10tons contruction trash transporting truck for sale
Construction trash transported truck is also called building waster transported truck, dump truck, tipper truck, sand and stone transporting vehicle, etc. This kind of special purpose vehicle is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction,construction building residue, etc. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
main technical parameters of Dongfeng 8-10tons dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. as below
Items | Descriptions | Specifications and Types |
General | Truck Name | Dump truck |
Drive Type | 4*2, lefthand driveor right hand drive | |
Fact LoadingCapacity(kg) | 10000 | |
Gross Vehicle Weight(kg) | 15990 | |
CurbWeight (kg) | 6295 | |
Overall Dimensions L*W*H(mm) | 7000×2490×2980 | |
Engine | Engine Model | B170 33 |
Fuel Type | Diesel | |
Power | 125kw/170HP | |
Emission Standard | Euro III | |
Displacement(ml) | 5900 | |
Engine Type | 4 cylinders in line,water cooling, turbo-charged diesel engine,inter-cooling | |
Chassis | ChassisBrand | Dongfeng |
Front/Rear Axle Load(KG) | 5990/10000 | |
Tire No. | 6 | |
Tire Specification | 9.00-20 Nylon tire or 9.00R20 steel tire | |
Wheelbase (mm) | 3950 | |
Axle No. | 2 | |
Gear Box | 6speedforward with 1 reverse,manual | |
Brake | Airbrake | |
Air Conditional | Optional | |
Front/rear suspension(mm) | 1430/1860 | |
Leaf Spring No. | 7/9+6 | |
Tipping system | Box inner dimension(mm) | 4480x2210x800 |
Box material | Carbon steel,side 3mm,bottom 4mm | |
Hydraulic cylinder no.(set) | 2 | |
Hydraulic cylinder diameter(mm) | 110 | |
Hydraulic cylinder position | At the center of the truck bottom | |
Discharge type | Rear tipping |
More pictures of CLW brand dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. as below
High quality and competitive price CLW brand dump truck for sale
Factory sale best price Dongfeng 8tons-10tons tipper truck
