HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck

HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck

    • HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck
    • HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck
    • HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck
    • HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck
  • HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck

    Product Details:

    Place of Origin: China
    Brand Name: dongfeng
    Certification: CCC, ISO 9001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package, waxed
    Delivery Time: 20 days
    Payment Terms: T/T, L/C
    Supply Ability: 20units/month
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request, Free To Paint Company Logo Price: High Quality Factory Direct Sale Price
    Truck Chassis: China Made High Quality Dongfeng T5 6*4 Diesel Truck Chassis

    HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck for sale



    Customized dongfeng T5 6*4 LHD 10tons telescopic crane boom mounted on truck adopts Dongfeng T5 T702 driver cab, yuchai 240hp/270hp diesel Euro 5 engine, 5850+1350MM wheelbase, fastgear 9 speed manual gearbox, 5.5tons front axle/10tons rear axles, 300mm boom, 11.00R20 rail tires, etc.



    The dimension of cargo body box is 8300×2300×550,600(mm), and the overall dimension of Dongfeng T5 4*2 LHD 8tosn telescopic truck mounted with crane is 11950×2490×3850,3650(mm). Client chooses to install CLW Brand high quality 6.3tons-8tons telescopic/knuckle crane boom.



    More pictures of customized dongfeng brand 6*4 T5 10tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.

    HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck

    customized dongfeng T5 10tons telescopic crane boom mounted on truck for sale

    HOT SALE! Dongfeng T5 6*4 LHD yuchai 240hp diesel 10tons telescopic cargo truck with crane, crane mounted on truck

    The specification of Dongfeng T5 6*4 LHD 10T telescopic crane boom mounted on truck as below.

    Product name Dongfeng T5 6*4 8tons telescopic boom mounted on truck for sale
    Chassis type EQ5180GLVJ
    Parameters Overall dimension length/width/height (mm) 11950×2490×3850,3650
    Cargo body dimension (L*W*H)(mm) 8300*2300*550mm
    GVW(kg) 25000(Kg)
    Kerb Mass(kg) 16250 (Kg)
    Rated mass(kg) 8620 (Kg)
    Approach angle/ Departure angle(mm) 26/10 (°)
    Front suspension/rear suspension(mm) 1450/3300
    Fuel Type diesel
    Max Speed 90
    Engine Type

    YC6A240-50

    YC6A270-50

    Displacement(ml)

    7520ml;

    7520ml

    Rated power(KW) 177KW/199KW
    Manufacturer Yuchai
    Chassis Drive Type 6*4
    Wheelbase(mm) 5850+1350MM
    Tread(front/rear) 1940, 1900/1900 (mm)
    Transmission Fastgear 9 speed manual gearbox
    Braking system Air braking
    Number of spring axle(front/rear) 9/13
    Tire Type 1100R20
    Air-condition Choose to install
    Upper part(cargo van and crane boom) main parameters
    Upper body Cargo body dimension 8300×2300×550,600(mm)
    Material Carbon steel
    Side sheet thickness 2mm thickness
    Bottom sheet thickness 2mm thickness
    Painting Upon request
    Crane boom main parameters
    Crane boom Choose to install CLW brand 10T 4 sections telescopic crane boom
    Crane boom lifting height 15.5m
    Crane boom working radius 13.5m
    Rotation Full hydraulic, full rotation
    The color of the whole truck is upon request.
