80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale

80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale

    • 80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale
    • 80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale
    • 80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale
    • 80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale
    • 80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale
  • 80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale

    Product Details:

    Place of Origin: China
    Brand Name: CLW
    Certification: ASME certificate

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package
    Delivery Time: 40 days
    Payment Terms: T/T
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request Price: High Quality Factory Direct Sale Price
    Material: High Quality Q345R Material For Lpg Gas Pressure Vessels

    80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale



    The integrative skid lpg gas filling station finishing discharging and filling by the pressure inside the tanker, and the working principles similar to the big size lpg gas filling station at home. The layouts of pipelines, such as inlet, outlet and gas phrase, etc. are reasonable, Practical, and artistic, etc.

    The skid mobile lpg gas propane station is mainly included bulk lpg gas tank, lpg gas pump, cut-off valve, motor, lpg gas disperser machine, filling scale, safety valve, etc.



    Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels, such as bulk lpg tank, lpg gas trailer, lpg gas truck, skid lpg gas filling plant, lpg gas bobtail vehicle, lpg gas dispensing truck, etc. And recently, our company lpg gas pressure vessesl products have passed ASME. That is to say, our lpg pressure vessels can be exported to USA, Europe, etc.

    > LPG storage tank with capacity of 5cbm up to 120cbm
    > Color : as per customer request
    > Dispenser:one gun or two gun dispenser available
    > LPG Filling pump with motor
    > LPG discharging pump with motor
    > LPG hose assembly and quick connector
    > Safety Valve+Liquid Level Indication + Pressure Gauge + Thermometer etc
    > Other valves and necessary accessories for the operation of lpg filling station.



    If you're interested in our skid lpg gas station, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wecgat/Mob.: +86 13329899995



    Main parameters of hot sale 80,000L mobile skid lpg gas refilling station manufactured by Chengli Special Automobile Co., Ltd. as below

    Item Unit Main parameters
    Product name   LPG gas storage tank(80000L)
    Product model   CLG3100-80
    Loading medium   LPG gas (propane)
    Overall dimension(L*W*H) mm 11166*3132*3722
    Tank dimension(inner diameter*thickness*length) mm DN3100*16*11166
    Tank volume m3 80
    Tank thickness mm 16
    End heads thickness mm 18
    Curb mass kg 17000
    Rated mass Kg 31920
    Designed pressure Mpa 1.77
    Working pressure Mpa ≤1.6
    Working temperature ≤50
    Hydraulic test pressure Mpa 2.22
    Air tight test pressure Mpa 1.77
    Tank and main Material pressure components Q345R,16Mnlll
    Standard
    <<GB150steel pressure vessel>>,<<Supervision Regulation on Safety Technology for Pressure Vessel>>



    Chosen assembly
    Safety valve, magic level gauge, pressure gauge, temperature gauge, cut-off valve, etc.





    Main parts of LPG Tank
    Item Specification Quantity
    Discharge Pipe DN50 1
    Inflow Pipe DN50 1
    Outlet DN50 1
    Gas phase balance pipes DN50 2
    Manhole DN450 1
    Drain Hole DN50 1
    Electronic LPG Filling Machine

    Can fill 0.5kg to 150kg gas cylinder

    with receipt printing

    1

    Main accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter,

    Pressure gauge, Temperature Gauge.

    Skid Parts List will be show in separated page below.



    The spare parts for the LPG Skid-station

      Model Number Quantity
    Tank 65CBM
    Cut-off Valve DN50 6 Pieces
    Cut-off Valve DN25 2 Pieces
    Cut-off Valve DN80 1 Pieces
    Needle Valve J24W, M20×1.5 1 Pieces
    Safety Valve DN80 1 Pieces
    Magnetic reversible level gauge UZFAL-2.5RF2640-0.50 1 Pieces
    Pressure gauge M20×1.5 1.5Level 0~4MPA 1 Pieces
    Thermometer M33×2 2.5Level 1 Pieces



    Accessory Quantity
    Cut-off Valve 9Pieces
    Shock-absorbing Tube 1 Set
    Filling pump machine 2 Pieces
    Discharge Pipe 5 Miters/set, 2sets
    Anti static electric motor 1 Piece
    Bottom Base 1 Unit
    Compressor 1.5MPa( choose to install, used to fill lpg gas truck)
    Freight To Shanghai Port

    More pictures of hot sale 80,000L skid lpg gas refilling plant manufactured  by Chengli Special Automobile Co., Ltd.

    80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale

    best price skid lpg gas refilling plant for sale

    80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale

    best price skid lpg gas plant for African Market

    More information, please feel free to contact with Ms. Anita Deng.

    Whatsapp/Wechat: +86 13329899995

    Skype: truck0011

    QQ: 504873236
