3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks

3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks

    • 3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks
    • 3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks
    • 3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks
    • 3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks
    • 3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks
  • 3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks

    Product Details:

    Place of Origin: China
    Brand Name: JAC brand

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package, waxed
    Delivery Time: 20 days
    Payment Terms: T/T, L/C
    Supply Ability: 20 units/month
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request Price: High Quaiity With Cheapest Price
    Truck Brand: China Leading JAC Truck Chassis

    3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks for sale



    Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of refrigerated truck, refrigerator truck, insulation body truck, reefer van truck, freezer van truck, etc. in China. With many years'experience in developing, Chengli Special Automobile Co., Ltd. could produce and supply high quality and competitive ISUZU refrigerated truck, dongfeng refrigerator truck, FAW freezer van truck, Foton reefer van truck, JAC insulation body truck, JMC refrigerated truck, refrigerated van semitrailer, etc. And the cooling units of the refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. can choose China faous brand or exported ones, and the temperature in the insulation body can be adjusted from -5 degree to -18 degree.

    The interior and exterior of the insulation body can be chosen the popular glass steel material, or stainless steel, aluminum alloy material, and the insulation van with strengthen, etc. the middle is PU slices with vacuum negative pressure one-formed casting, and the thickness is 80mm, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. The refrigerated van has the advantages of high strength; strong anti-corrosion and aging resistance, low heat-conducting property, non-pollution, non-easy destroy, etc. And the baseboard is aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. There are aluminum alloy ventilation slots on the baseboard. The frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc. The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability. Door edgings, door locks and accessories use stainless steel materials.



    If you're interested in our truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995



    The main parameters of JAC mini cold room truck as below



    Item Parameter
    Production name refrigerator truck
    vehicle model HFC5040XLCL3K2T
    Engine Engine model: HFC4DA1-2B2
    Engine manufacturer: JAC Automobile Co., LTD
    Exhaust: 2771ml
    Power: 88kw
    Chassis model HFC1042L3K4T
    Tire Tire specification: 7.00-16
    Number of tire:6
    Axle Number of axles: 2
    Axle-load: 1555/2765
    Wheel base(mm): 3360
    Traction system 4*2
    Tank fact cubage(cbm) 4-5
    GVW(kg) 4320
    Curb weight(kg) 2700
    Rated load(kg) 1490
    Overall dimensions(mm) 5995×1910×2900
    F / R track base(mm) 1440/1425
    F/R overhang(mm) 1105/1530
    Approach / departure angle(°) 24/15
    Max speed(Km/h) 98
    Equipment and Function

    Equipment: chassis, the heat preservation box body--standard material is glass fiber reinforced plastic,

    8mm polyurethane insulation layer,

    Standard back open door and refrigeration unit; Optional: polyurethane material,

    color steel plate,

    stainless steel, etc, 5mm insulation layer, side open door;

    Function: transport frozen foods (ice truck), dairy (milk truck) fruits and vegetables

    (fresh transporter) vaccine and drug transporter (vaccine truck), etc



    More pictures of hot sale JAC brand mini refrigerated truck as below

    3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks

    3ton mini Jac small freezer truck thermo king meat transportation cooling van truck jac mini refrigerated trucks



    Chengli Special Automobile Co., Ltd manufactures refrigerator trucks since 2004s in China. With so many years’ experience in manufacturing, we Chengli Special Automobile Co. Ltd could manufacture and sell vaccine delivery vehicle, meat hook refrigerated truck, fruit and vegetables refrigerated truck, milk food transport refrigerator truck, insulation van truck, van refrigerated truck, freezer minibus, small refrigerated truck, medium freezer van truck, big refrigerated truck, refrigerator semi-trailer, freezer refrigerated vehicles, dongfeng brand cold room truck, ISUZU brand refrigerated truck, FAW refrigerated truck, FOTON refrigerated truck, Chang’an freezer van truck, Yuejin refrigerated truck, JMC refrigerated truck, CMAC refrigerator truck, Aoling refrigerated truck, the smallest refrigerated truck, etc.More information, please feel free to contact with Ms. Anita.

    Whatsapp/wechat: +86 13329899995

    Skype: truck0011

    QQ: 504873236
