customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale

customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale

    • customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale
    • customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale
    • customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale
    • customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale
  • customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale

    Product Details:

    Place of Origin: China
    Brand Name: CLW
    Certification: CCC, ISO 9001,ASME

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package, waxed
    Delivery Time: 20 days
    Payment Terms: T/T, L/C
    Supply Ability: 20units/month
    Contact Now
    Detailed Product Description
    Color: Free To Paint Company Logo, Different Color Upon Request Material: High Quality Q345R/Q370 Material Special For Lpg Gas Pressure Vessels
    Price: High Quality Factory Direct Sale Price Manufacturing Standard: China Standard Or USA ASME Standard



    customized 10tons mobile skid lpg gas station with lpg gas dispenser of double filling nozzles for sale, Factory sale cheaper price CLW brand skid propane gas plant with lpg filling dispenser



    Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years' development, we Chengli could manufacture and sell surface and underground lpg gas storgae tanks, lpg gas tank trailer, skid lpg gas refilling station, lpg gas truck, etc. More information, please feel free to contact with Ms. Anita Deng.


    Nowadays, more and more clients choose to purchase mobile skid lpg gas plant for their lpg gas plant business. We Chengli Special Automobile Co., Ltd. can customize skid lpg gas plant with digital scales for filling domestic gas cylinders or automatic lpg gas dispenser for automobiles or gas cylinders. The lpg gas dispensing machine is with single filling gun or double filling guns for filling single gas cylinders or double gas cylinders at one time.



    The skid lpg gas station is not only required safe and also reliable, the most importantly practical. The skid liquefied gas pumping station doesn’t have enough space like the liquefied gas station to arrange the equipment. The designers need to conceive how to arrange the supporting equipment in a small space and let it be safe for work. The working principle of skid lpg gas refilling plant mainly as below.

    1, there must be safe and reliable circuit systems, pumps, digital filling scales and gas compressors, etc. all electricity to drive. At the same time, the circuit must be designed to be simple and easy to operate, too. When to purchase the motors, it is necessary to purchase the explosion-proof anti-static type fort the liquefied gas sparked and the concentration is too high and easy to explode.
    2, the complete liquid phase, gas phase and reflux system, which require the designed to be very familiar with the principle of the liquefied gas station. When the liquid phase, gas phase are connected with the tank truck of the skid lpg plant, the liquefied gas in the tank is on the compressor.
    Fill the tank under pressure. However, the volume of the skid lpg gas station is generally small. If the loading and unloading operation speed is too fast, the tank of the skid station can not accommodate too much liquefied petroleum gas at a time, and there is a danger. Therefore, the designer will design a return line on the liquid phase pipeline and install a safety valve on the pipeline. Once the pressure inside the pipeline is too large, the safety valve will jump open and leak excess liquefied gas propane, thus ensuring the overall Safety.
    3. The emergency shut-off valve and concentration alarm will be installed in the place where the tank of the liquefied gas pumping station is connected with the pipeline. Once a leak or sudden situation occurs, double insurance can be provided.



    If you're interested in our CLW Brand skid lpg gas refilling station, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995



    More pictures of CLW brand new 10tons skid lpg gas refilling station with lpg gas dispenser customized for overseas clients as below.

    customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale

    high quality and competitive price CLW brand skid lpg gas tank with lpg gas dispenser for sale

    customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale

    Factory sale best price CLW brand skid-mounted lpg gas refilling station with lpg gas dispenser of double nozzles

    customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale

    customized 10tons skid lpg gas station with lpg gas dispenser of 2 filling nozzles for sale, skid lpg tank for sale

    main technical parameters of CLW brand 10tons skid lpg gas refilling station manufactured by Chengli Special Automobile Co., Ltd. as below.

    Item Model Unit No. Remark
    Lpg gas storage tank 20,000Liters/10tons Piece 1 Standard skid with low frame base (designed into load one 40’HQ container)
    Hydrocarbon pump YQB15-5 Piece 1 Driving belt with cover,pump base
    Explosion-proof three-phase asynchronous motor 5.5KW Piece 1
    Concentration alarm - Piece 1
    Lpg gas dispenser(with double filling nozzles) China made Piece 1
    Explosion-proof control box - Piece 1
    Floating ball level meter UQZ-6 Piece 1
    Temperature gauge M33*1.5 1.5 grade 0~4mpa Piece 2
    Safety valve DN80 Piece 1
    Globe valve DN80 Piece 1
    Safety backflow valve AH42F-25 DN25 Piece 1
    Y-Strainer GL41H-25 DN50 Piece 2
    Globe valve J41W-40 DN50 Piece 5
    Ball valve/check Q41F-40 DN50 Piece 5
    Discharging pipe L=4m DN50 Piece 2
    check valve M42N-25 DN50 Piece 1
    Sprinkling   Piece 1 Galvanized tube
    Needle valve DN6 Piece 3
    Ball valve DN15 Piece 1
    damper tube - Piece 1
