|Place of Origin:||China|
|Certification:||CCC, ISO 9001|
|Minimum Order Quantity:||1 unit|
|Packaging Details:||in bulk package, waxed|
|Delivery Time:||20 days|
|Payment Terms:||T/T, L/C|
|Color:||Different Color Upon Request, Free To Paint Company Logo||Price:||High Quality Factory Direct Sale Price|
|Truck Chassis:||Chinamade HYUNDAI LHD Diesel Truck Chassis||TYPE:||Normal Type. Standard Type, Intelliegnt Type|
Customized HYUNDAI brand 4*2 LHD 130hp diesel 4cbm 3tons intelliegent asphalt distributing vehicle for sale, China made bitumen tanker spreading truck for sale
HYUNDAI brand 4*2 LHD 4cbm asphalt spreading tanker truck, adopts Customized intelligent type asphalt tanker vehicle adopts HYUNDAI 4*2 LHD single row driver cab, ISF2.8S5129T 130 diesel Euro 5 engine, 6 speed gearbox, 7.00R16 tires*6+1, 3300mm wheelbase, 3.5tons rear axle, power steering, air cut braking, radio+MP3, air conditioner, etc.
The devices of intelligent type HYUNDAI brand 4cbm 3tons intelligent type asphalt distributing vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
1, the asphalt pump adopts high quality QGB680 (high viscosity asphalt pump, 680L/min).
2, hydraulic system: the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L;Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve, radiator adopts Risheng brand.
3, control way: Intelligent touch screen computer control in the cab; control system: (Siemens, Germany), 30 intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G10)+ Automatic heating of heat transfer oil
5, gasoline generator unit: 6KW
6, asphalt distributing width: 4m; spreading amount: 0.25-2.5L/㎡
7, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt
If you're interested in our asphalt tanker truck, please send email to firstname.lastname@example.org or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of HYUNDAI asphalt spreading tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of HYUNDAI brand 4*2 LHD 4cbm bitumen tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below
|Main technical parameters|
|Product name||asphalt tanker truck for sale|
|Total mass(Kg)||7300||Tanker volume(m3)||4|
|Rated mass(Kg)||2690,2625||Overall dimension(L*W*H)(mm)||6300×2080×2830|
|Curb mass(Kg)||4480||Driver cab seated person||2|
|Approach/departure angle(°)||21/16||Front/rear suspension(mm)||1125/1570|
|Axle load(Kg)||1700/2795||Max speed(Km/h)||110|
|Chassis main parameters|
|Appracoh/departure angle(°)||21/18||Tire specification||7.00R16 14PR*6|
|Steel spring||4/5+3,||Front tread(mm)||1680|
|Fuel type||Diesel||Rear tread(mm)||1495|
|Emission standard||Euro Ⅲ|
Asphalt distributor is a kind of pavement construction machinery; it is a highway, urban road, airport and port construction of major equipment.It can be used to transport and makes liquid asphalt (including hot asphalt, emulsified asphalt and residue) . The bitumen distributor truck are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48.
The emulsified asphalt distributor truck is also called asphalt paver, asphalt sprayer truck, bitumen sprayer truck, asphalt distributor truck, asphalt bitumen tank truck, road sealer truck, asphalt truck, etc. The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
The asphalt distributor trucks manufactured by Chengli Special Automobile Co., Ltd. adopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.
Advantages of sensor emulsified asphalt sprayer truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1.The temperature rising speed is 5% faster than the trucks manufacture by other factory.
2.With conducting oil system, asphalt both in the tank and in the nozzle are all hot, easy to spray, no remained.
3.High quality metal hose, won't broken, long service life.
4.The distribution width can be adjusted according to your demand from 4.5m to 6m.
5.Start quickly, though the truck stop, still can distribute.
