customized standard type Dongfeng D9 190hp diesel 12cbm asphalt tanker truck for sale, pitch bitumen tanker truck

customized standard type Dongfeng D9 190hp diesel 12cbm asphalt tanker truck for sale, HOT SALE! pitch bitumen tanker truck

CLW asphalt tank distributing vehicle is a kind intelligent automated high-tech special vehicle for distributing different kinds of asphalts such as emulsified asphalt, diluted asphalt, hot asphalt, High viscosity modified asphalt, etc. It is used for distributing the permeable oil waterproof layer on the bottom of asphalt pavement of high grade highways. The asphalt distributing vehicle is made up of truck chassis, asphalt tank body, asphalt pump delivering and spraying system, thermal oil heating system, hydraulic system, combustion system, control system, Pneumatic system, operation platform, etc.

It is very easy to operate this asphalt distributing vehicle, based on the technology of similar products at home and abroad; at the same time increased quality and technical content to ensure construction, Highlight improvement of construction conditions and humanized Design of Construction Environment. The reasonable and reliable design ensures Evenness of asphalt sprinkling, Computer controlling is stable and reliable and Vehicle technical performance has reached the world advanced level, etc. With all the improvements we've made, our CLW brand asphalt distributing vehicle can work in worse conditions.

Dongfeng brand 4*2 12bm asphalt spreading tanker truck, adopts dongfeng Tianjin 4*2 RHD one row and a half driver cab, B190 33 190hp diesel engine, 8 speed gearbox, 5tons front axle/10tons rear axle, 4500mm wheelbase, power steering and air cut braking, 10.00R20 rail tires*6+1, etc.

The devices of dongfeng D9 12bm standard type asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. is as below.

1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).

2, hydraulic system: manual Proportional valve; radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L or Power take off after engine GPC4-50R.

3, control way: controlled the control box at the rear working platform, 36 sets intelligent asphalt spraying nozzles (one controls one).

4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil.

5, asphalt distributing width: 4.5m,

6, spreading amount: 0.25-3.5L/㎡;

7, gasoline generator unit: 6KW

• Product name: dongfeng D9 4*2 LHD asphalt tanker truck(standard type)
• Total mass: 16000kg
• Curb mass: 9400kg
• Asphalt tanker volume: 12,000Liters
• Overall dimension(L*W*H): 8590×2500×3250mm
• Spreading/distributing width: 4500mm
• Spraying nozzles spacing: 125mm
• Asphalt spreading amount: 0.2～3.5L/m²
• Working speed: 1.5--20km/h
• Heating method: Italy imported diesel burner(G20 model, 200Kcar/Hour)
• Distributing medium: hot asphalt, SBS modified bitumen, emulsified asphalt, modified emulsified asphalt
• Spreading error: ±2%

More pictures of DONGFENG D9 12cbm asphalt tanker truck as below.

main technical parameters of DONGFNEG D9 190hp diesel asphalt distributing tanker truck as below.
