HOT SALE! dongfeng 4*2 RHD smaller 95hp diesel road sweeping truck, customized dongfeng 4*2 RHD diesel street sweeper
| 1 main parameters |
| Product name |
CLW5061TSL3 road sweeper truck |
Remark |
| Chassis model |
EQ1060TJ20D3 |
|
| Wheelbase |
3300mm |
|
| Front/rear suspension |
1032/1638(mm) |
|
| Engine model |
Truck chassis engine |
CY4102-C3F |
|
| Auxiliary engine |
JX493-G3 |
|
| Output power |
Truck chassis engine power |
70KW |
|
| Auxiliary engine power |
57 KW |
|
| Max Gradient |
30% |
|
| Emission standard |
Euro Ⅲ |
|
| Outside-automobile noisy in the accelerating |
≤84dB(A), meeting the noisy of Second stage requirements |
|
| Max speed |
95 km/h |
|
| Approach angle |
19° |
|
| Departure angle |
12° |
|
| Weight |
Curb weight |
4800 kg |
|
| Max total weight |
7300kg |
|
| Dimension |
Overall dimension(L×W×H) |
5950×1995×2380mm |
|
| Mini ground clearance |
240mm |
|
| Sucking and sweeping working |
Sweeping efficiency |
≥95% |
|
| Max sucking granularity |
120mm |
|
| Sucking-sweeping width |
2.8-3.0 m |
|
| Max sweeping ability |
60000 m2/h |
|
| Extension dimension of dish brush |
≥400 mm |
|
| |
Sucking disk driving speed |
3-20km/h |
|
| Tanker |
Water tank volume |
1.0-1.5m³ |
|
| Material |
Stainless steel |
|
| Wastes van |
Wastes van loading capacity |
3.5-4.0m³ |
|
| Open angle of the discharging door |
≥45° |
|
| Material |
Stainless steel |
|
| Hydraulic system |
Type |
Open-type, electronic-control |
|
| Main units |
Gear pump, hydraulic motor, hydraulic cylinders, solenoid valve, |
|
| System pressure |
16MPa |
|
| Hydraulic oil tank volume |
60L |
|
| Oil temperature |
60 ˚C |
|
| Electronic |
Type |
DC24V |
|
| voltage |
24V |
|
| Storage battery |
24V(2 sets of 12V in series) |
|
| Water sprinkling system |
Main units |
Electronic diaphragm pump, water filter, nozzles, |
|
| Sweeping disks device |
Type |
4 sets of sweeping disks middle-installed driving by hydraulic motor;
The right-front one can work separately, with the function of dodge and repeat working
|
|
| Diameter |
850mm |
|
| Angle |
ante version:4-6 °; extroversion: 4-7° |
|
| Sucking disk |
Tyre |
Single sucking, hydraulic-control, spring s |
|
| Sucking diameter |
200mm |
|
| Other device |
Rear part |
With LED arrow indication light |
|
| |
|
|
|
|
More pictures of Dongfeng 4*2 RHD road sweeping truck manufactured by Chengli Special Automobile Co., Ltd. as below
high quality and competitive price dongfeng road sweeper truck for sale
Factory sale best price dongfeng RHD street sweeping vehicle
The main technical advantages of CLW ROAD sweeper trucks manufactured by Chengli Special Automobile Co., Ltd. as below
1, the control box is at the driver cab, different electronics is centralized, flexible operation.
2, there are four sweeping disks and sucking working tog, perfect sweeping-sucking performance, and the sweeping disks with anti-collision function.
3, the sweeping brushes at the right side and the left sides can work at the same time, just one side sweeper working.
4, the sweeping cleaning device is with simple, reliable, etc.
5, the garbage vans and the cleaning water van adopts high quality stainless steel.
6, the hydraulic KEY units are imported.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of road sweeper truck in China. With many years’ development, we can offer ISUZU road sweeper truck, dongfeng street sweeper truck, forland road sweeping vehicle, YUEJIN road sweeper, JMC road sweeper truck, etc. More information, please feel free to contact with Ms. Anita.
