Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of road sweeper trucks in China. With many years’ development, we Chengli Special Automobile Co., Ltd. could offer ISUZU road sweeper truck, forland street sweeper truck, dongfeng brand road cleaning vehicle, JMC brand road sweeping vehicle, JAC brand street sweeper, FAW brand street sweeping vehicle, etc. More information, please feel free to contact with Ms. Anita
Dongfeng tuyi mini gasoline mini road sweeping vehicle, adopts Chang’an 4*2 LHD gasoline smallest road sweeping truck, adopts Chang’an 4*2 LHD single row driver cab, electric EPS power steering, Chongqing power DK12-10 Euro 5 gasoline 88hp engine, 5 speed gearbox, front-disc and rear drum braking, 165R15 vacuum tires, etc.
There are 4 sets middle-installed sweeping plates, SANYO motor, LN 31hp auxiliary engine, Schneider controlling switches, HI-PRESSURE solenoid valves, Continuously variable automatic clutch, maintenance-free centrifugal fan, stainless steel dust tank, Polaris brand Electronic pump, dust tank lifting and tipping, rear part with arrow LED lamp, Manual pump emergency system ,etc.
If you're interested in our refrigerated truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of dongfeng gasoline road sweeping vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
high quality and competiive price Dongfeng gasoline road sweeper truck for sale
HOT SALE! Customized dongfeng gasoline road sweeper truck for slae
More information, please contact with Ms. Anita.
Whatsapp/Wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
main technical parameters of dongfeng tuyi 4*2 LHD gasoline road sweeping truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Main technical parameters |
| Product name |
Dongfeng tuyi brand 4*2 LHD mini gasoline road sweeping truck for sale |
| Total mass(Kg) |
3495 |
Overall dimension(L*W*H)(mm) |
5020*1680*2200 |
| Rated mass(Kg) |
360 |
Curb mass(Kg) |
3000 |
| Driver cab seated person |
2 |
Front/rear suspension(mm) |
1181/1239 |
| Approach/departure angle(°) |
20/18 |
wheelbase(mm) |
2600 |
| Alxe nos. |
2 |
Max speed(Km/h) |
110 |
| Axle load(Kg) |
1300/2195 |
Emission standard |
Euro Ⅴ |
| Chassis main parameters |
| Truck chassis |
EQ1033SJ15QC |
Tires nos. |
6 |
| Approach/departure angle(°) |
20/20 |
Tire specification |
6.00-13 8PR |
| Steel spring |
3/5 |
Front tread(mm) |
1369 |
| Fuel type |
gasoline |
Rear tread(mm) |
1214 |
| Engine model |
Manufacturer |
displacement(ml) |
power(KW) |
| LJ4A15Q |
Wulin liuji |
1499 |
79.5 |
| Sweeping devices |
1, the volume of the stainless steel is 0.8cbm; while the volume of the stainless steel dust hopper is 1.7cbm.
2, middle-installed sucking disk,
3, Schneider control switch
4, LN 31hp auxiliary engine
5, stainless steel dust hopper
6, HI-PRESSURE electromagnetic valve unit.
7, infinite variable speed automatic clutch,
8, maintenance-free centrifugal fan,
9, high precision filter system for the dust hopper(max up to 0.3micronmeter),
10, imported sentinel valve,
11, tail with LED arrow lamp,
12, manual pump emergency system
13, tail with mist spraying and wetting system
|
