2020s new design biggest 62m3 bulk lpg gas tank semitrailer for sale, best price road transported lpg gas tank for sale
Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl , methanol, butadiene, butane, ethylene oxide, etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 120 cubic optional. Besides, the lpg gas tank, Chengli Special Automobile Co., Ltd. could offer lpg gas trailer, lpg gas tank, lpg gas delivery truck, lpg gas dispenser vehicle, skid lpg gas filling plant, etc. More information, please feel free to contact with Ms. Anita Deng.
Function characteristic of liquefied gas truck of chengli factory
The anti corrosion coating of liquefied gas semi-trailer adopt the following process:sandblast,spray painting,purging and so on
There are domestic or imported safety accessories with high quality ,its matching is complete
We adopt scientific advanced construction process strictly,ensure that the products are with the lowest shrinkage and the highest dimensional stability at low temperature
We inspect the quality of product strictly,ensure that A and Btype of welding seam pass the examination of level two radiographic test C and D type of welding seam pass the examination of
Level one radiographic test.
If you're interested in our biggest 62m3 bulk lpg gas tank trailer, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
More pictures of CLW Brand biggest lpg gas tank trailer manufactured by Chengli Special Automobile Co.,Ltd. as below.
high quality and competitive price CLW Brand lpg gas tank trailer for sale
HOT SALE! CLW Brand 62cbm lpg gas tank semitrailer
Customized CLW Brand 62,000Liters lpg gas tank trailer for sale
main technical parameters of CLW Brand biggest lpg gas tank semitrailer manufactured by CHENGLI SPECIAL AUTOMOBILE CO., LTD. as below.
| Main parameters |
| Product name |
Lpg gas trailer for propane |
Product model |
CLW9401GYQC Lpg gas tank semitrailer |
| Total mass(Kg) |
40000 |
Tank volume(m3) |
585 |
| Rated mass(Kg) |
26000 |
Overall dimension(mm) |
13590×2550×3995 |
| Curb mass(Kg) |
14000 |
Cargo body dimension(mm) |
×× |
| Approach/departure angle(°) |
-/21 |
Front/rear suspension (mm) |
-/1940 |
| Axle nos. |
3 |
Wheelbase(mm) |
7010+1310+1310 |
| Axle load(Kg) |
-/24000(triple axles) |
Max speed(Km/h) |
|
| Remark |
The transporting medium: propane, and the density: 0.42tons/cbm-0.52tons/cbm;
The lpg gas tank volume: 61.9cubic meters.
Tank overall dimension(Length*diameter): 13,230*2545(mm), |
| Chassis main parameters |
| Overall dimension (mm) |
13590×2550×3995 |
Tyre nos. |
12+1 |
| Approach/departure angle(°) |
-/19 |
Tyre specification |
11.00R20 12PR,12R22.5 12PR |
| Steel spring |
-/4/4/4,-/7/7/7 |
Front tread(mm) |
|
| Fuel type |
|
Rear tread(mm) |
1840/1840/1840 |
61.9cbm LPG tanker semitrailer for LPG GAS adopts 13ton FUWA triple axles, 12 sets 12.00-20 vacuum tyre, and another spare tyre, JOST 28ton outrigger, JOST 50# traction pin, fire extinguisher bottle, anti-static tape.
The standard devices are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton FUWA bridges, 12+1sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, ABS etc.
The LPG tanker semi-trailer is line with the GB150-1998, <<Supervision Regulation On Safety Technology for Pressure Vessel>>, <<Regulation of Safety Supervision for Liquefied Gas Tank Car>>.
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
