Factory sale good price dongfeng 4*2 LHD/RHD cargo truck with 2tons folded crane boom, 2ton small cargo truck with folded crane boom for sale
CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.
Product Notes of CLW brand truck mounted crane manufactured by Chengli Special Automobile Co., Ltd. as below.
· Optional: from 2 ton to 200 ton lifting capacity crane truck
· Optional: straight arm and floding arm truck crane with or without remote control
· Optional: different famous crane brand: HIAB, Shimei, Zoomlion, Sany, Chengli balong, etc.
· Optional: different famous chassis brand: Dongfeng, FAW, Foton, Sinotruk, Syter, Shaanxi, T-king, Dayun, Yuejin, JMC, JAC, etc.
· Factory direct sale, low price and good quality.
If you're interested in our truck mounted on crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of dongfeng brand 4*2 LHD 2tons small cargo truck with telescopic boom manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! Dongfeng 2tons folded boom mounted on truck
High quality and competitive price Dongfeng brand 2tons cargo truck with folded boom for sale
main technical parameters of Dongfeng brand 2tons small cargo truck with crane manufactured by Chengli Special Automobile Co., Ltd. as below.
| Dongfeng 2ton small cargo truck with folded crane boom main Technical Parameter |
| Product Model |
Dongfeng 4*2 LHD truck with crane |
Gross Vehicle Weight (kg) |
6495 |
| Curb Weight (kg) |
3865 |
Overall Dimension(mm) |
5995x1980x2950 |
| Lifting Capacity(kg) |
2000 |
Cargo body dimension(mm) |
3500*1980*400 |
| Axle No. |
2 |
Wheelbase (mm) |
3300 |
| Chassis Technical Parameter |
| Chassis Model |
EQ1060TJ20D3 |
Chassis Name |
Truck Chassis |
| Chassis Brand |
Dongfeng |
Manufacturer |
Dongfeng Automobile Co., Ltd |
| Overall Dimension (mm) |
5820×1940×2080 |
Tyre No. |
6 with 1 spare tyre |
| App./ Dep. Angle(º) |
19/15 |
Tyre Spec. |
7.00-16 |
| Leaf Spring No. |
8/9+5 |
Front Track (mm) |
1506 |
| Fuel Type |
Diesel |
Rear Track (mm) |
1466 |
| Drive Type |
4x2 LHD, RHD is selective. |
Brake System |
Air brake |
| Steering Type |
Circulate ball |
Gear Box |
5 speed forward and 1 reverse |
| Engine Technical Parameter |
| Engine Model |
CY4100 |
Emission Standard |
Euro III |
| Displacement ( mL ) |
3856 |
Power (hp/kw) |
95hp/70kw |
| Cylinder No. |
4 cylinders in line |
Engine Type |
Water cooling, four stroke, inter-cooling charged, |
| Crane boom technical parameters |
| Cargo body dimension(L*W*H)(mm) |
3500*1980*400 |
Boom model |
SQ2ZA1 |
| Max lifting capacity |
2,000kgs |
Working radius |
5.1m |
| Boom lifting height(m) |
6.8m |
Curb mass |
850kgs |
| More information of the price, please contact with Ms. Anita. |
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.
