|Place of Origin:||China|
|Certification:||CCC, ISO 9001， ASME|
|Minimum Order Quantity:||1 unit|
|Packaging Details:||in bulk package, waxed|
|Payment Terms:||T/T, L/C|
|Color:||Differnet Color Upon Request||Price:||High Quality And Competitive Price|
|Material:||High Quality Q345R Material For Lpg Gas Pressure Vessels||Volume:||5,000Liters To 50,000Liters Upon Request|
HOT SALE! 2019s high quality and competitive price CLW brand 8,000Liters cooking gas tank with digital scales,
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years'development, Chengli Special Automobile Co., Ltd. could manufacture and supply surface/underground lpg gas storage tank, lpg gas tank semitrailer, skid lpg gas refilling plant, lpg gas truck, lpg gas bobtail vehicle, etc.
The skid system tank with automobile lpg gas dispenser manufactured by Chengli Special Automobile Co., Ltd. is used for refilling of liquified petrol gas (LPG). As a major equipment of the LPG station, it is equipped with high-accuracy positive displacement flowmeter,microcomputer control, large LCD counter and various control valves and protection devices assuring operation safety.With advanced manufacturing technique, the dispenser has reliable quality and excellent performance with characteristics of precise ration, easy maintainance and centralized control. Each gun connects to an independent flow and metering system which prevents interference.
If you're interested in our CLW brand skid lpg gas refilling station, please send email to email@example.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
More pictures of skid lpg gas refilling station with lpg gas dispenser manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! Customized skid lpg gas station with digital scale for sale
high quality and competitive price CLW Brand mobile skid lpg gas station for sale
main technical parameters of skid lpg gas refilling station with lpg gas dispenser manufactured by Chengli Special Automobile Co., Ltd. as below.
|LPG SKID STATION DIMENSIONS|
|Volume of Tank||8,000L|
|Filling Weight||3192 kgs|
|Tank Weight||2540 kgs|
|Thickness of Shell (mm)||10 mm|
|Thickness of Endplate (mm)||10 mm|
|Tank Diameter (mm)||1600 mm|
|External Dimensions (mm) (length x width x height)||5070x 1650 x 2910 mm|
|Material of Tank and Main Pressure Parts||Carbon Steel Q345R|
|Filling Medium||Liquefied Petroleum Gas ( Propane)|
|Design Pressure||1.77 MPa|
|Corrosion Allowance||1 mm|
|Medium Density||420 kg/ cbm|
|Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China.|
|Main parts of LPG Tank|
|Gas phase balance pipes||DN50||2|
|Electronic LPG Filling Machine||
Can fill 0.5kg to 150kg gas cylinder
with receipt printing
Main accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter,
Pressure gauge, Temperature Gauge.
Skid Parts List will be show in separated page below.
The spare parts for the LPG Skid-station
|Cut-off Valve||DN50||6 Pieces|
|Cut-off Valve||DN25||2 Pieces|
|Cut-off Valve||DN50||1 Pieces|
|Needle Valve||J24W, M20×1.5||1 Pieces|
|Safety Valve||DN50||1 Pieces|
|Magnetic reversible level gauge||UZFAL-2.5RF2640-0.50||1 Pieces|
|Pressure gauge||M20×1.5 1.5Level 0～4MPA||1 Pieces|
|Thermometer||M33×2 2.5Level||1 Pieces|
|Shock-absorbing Tube||1 Set|
|Filling pump machine||2 Pieces|
|Discharge Pipe||5 Miters/set, 2sets|
|Anti static electric motor||1 Piece|
|Bottom Base||1 Unit|
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China since 2004s. With many years’ development, we could offer Lpg gas skid station, is also called skid system lpg station, propane lpg skid-mounted filling station, lpg mounted skid refilling station, mobile lpg filling station, lpg skid station with dispenser and weight scale, lpg gas cylinder filling station, etc. And our CLW skid lpg gas filling stations is from 2tons to 40tons. More information, please feel free to contact with Ms. Anita Deng.
Whatsapp/Wechat: +86 13329899995
