new brand dongfeng double-cab 2tons folded crane boom mounted on truck for sale, hot sale best price truck with knuckle crane
the technical features of dongfeng 4*2 LHD double cabs 2tons folded crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Single cyliner synchronization guy cable technology make work efficiency more higher
The more symmetrical center design of pentagon hexagon boom make it has bigger anti-bending capacity.
The work is more safety after ftted with over wind alarm equipment
The integer lifting winch improved the work efficiency greatly and prolonged work life of hydraulic system
Float three-point bridge structure design can lower the accessional stress on the chassis when traveling.
Anti-slewing impulse equipment that make vehicle running safely
The rear leg to ensure the safety during the lifting
The operation can be done on the ground or in the air, the operator can see the cargo loading condition during his operation.
if you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of dongfeng double cabs 2tons folded crane boom mounted on cargo truck as below.
high quality and competitive price dongfeng double cabs 2tons folded crane boom on truck for sale
HOT SALE! Best price 2tons telescopic boom mounted on truck
main technical parameters of dongfeng 2tons folded crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
Dongfeng duolika LHD/RHD 2 tons folded crane boom mounted on truck for sale (CLW5050JSQ3) |
| Chassis type |
EQ1050NJ20D3 |
| Parameters |
Overall dimension length/width/height (mm) |
5995×2000×2900 |
| Cargo body dimension (L*W*H)(mm) |
2850×1880,1800×400 |
| GVW(kg) |
5495 (Kg) |
| Kerb Mass(kg) |
3270 (Kg) |
| Rated mass(kg) |
1900(Kg) |
| Approach angle/ Departure angle(mm) |
19/15 (°) |
| Front suspension/rear suspension(mm) |
1032/1663 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
CY4100Q |
| Displacement/Power(kw) |
3856ml/70KW/95hp |
| Manufacturer |
Dongfeng chaochai Engine Co.,Ltd |
| Type |
4-in-line inter-cooling; intercooling |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
3300 |
| Tread(front/rear) |
1404,1506/1458,1466 (mm) |
| Transmission |
5 forward gear,1 reverse gear, mechanical transmission |
| Braking system |
Air braking |
| Cab |
Dongfeng single row driver cab |
| Number of spring axle(front/rear) |
8/9+5,6/8+4 |
| Tire Type |
7.00-16 |
| Air-condition |
Choose to fix |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
2850×1880,1800×400 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
3mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 2T 2/3 sections folded crane boom |
| The color of the whole truck is upon request. |
