best seller dongfeng 4*2 LHD Euro 5 156hp diesel 4tons telescopic boom mounted on truck for sale, factory sale dongfeng 4tons cargo truck with crane
Customized truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our dongfeng brand 156hp diesel 4tons telescopic boom mounted on truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More picutres of dongfeng brand Euro 5 156hp diesel 4tons telescopic boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
high quality and competitive price dongfeng 4tons telescopic truck with crane for sale
Factory sale best price dongfeng 4tons truck with crane for sale
main technical parameters of dongfeng brand 156hp diesel 4tons telescopic boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
Dongfeng 4*2 LHD 156hp Euro 5 4tons telescopic boom mounted on truck for sale |
| Chassis type |
EQ1090SJ8BDE |
| Parameters |
Overall dimension length/width/height (mm) |
7995×2320×3250 |
| Cargo body dimension (L*W*H)(mm) |
5200×2150×550 |
| GVW(kg) |
9400 (Kg) |
| Kerb Mass(kg) |
5500 (Kg) |
| Rated mass(kg) |
3705 (Kg) |
| Approach angle/ Departure angle(mm) |
21.5/12 (°) |
| Front suspension/rear suspension(mm) |
1180/2415 |
| Fuel Type |
diesel |
| Max Speed |
103 |
| Engine |
Type |
CY4SK251 |
| Displacement/Power(kw) |
3856ml/115KW/156hp |
| Manufacturer |
Dongfeng chaochai diesel engine |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
4400 |
| Tread(front/rear) |
1745/1640,1800 (mm) |
| Transmission |
6 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
Dongfeng single row driver cab |
| Number of spring axle(front/rear) |
8/10+7 |
| Tire Type |
8.25R16 14PR rail tires* 6+1 |
| Air-condition |
Choose to install |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
5200×2150×550 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 4tons telescopic crane boom |
| Rotation |
Full hydraulic, full rotation |
| The color of the whole truck is upon request. |
Chengli Special Automobile Co., Ltd. is the leading manufacturer of truck with crane, truck mounted crane, dump truck with crane, cargo truck with crane, telescopic crane mounted on truck, etc. With many years’ experience in manufacturing, Chengli Special Automobile Co., Ltd. could manufacture and supply 4*2 small truck with crane, 4*4 truck with crane, 6*2 dump truck with crane, 6*4 cargo truck with crane, 8*4 crane monted on truck, etc. And the CLW brand cranes are from 2.5ton to 20 ton, and much bigger for different trucks. Chengli Special Automobile Co., Ltd. coulkd design and produce the trucks according to customers’ requirements. More information, please feel free to contact with us.
